Carries 10 Gigabit fiber links between switches and servers

A multimode SFP+ optical transceiver module for the 10GBASE-SR interface. It serves the short-reach fiber runs between the backbone and the access layer in campus and data center networks, and goes straight into switches with an SFP+ cage.

10.3125 GbpsData rate

SFP+Form factor

850 nmWavelength

300 mOM3 fiber reach

Duplex LCConnector Type

1.5 WMax. power consumption

Key features

10.3125Gbps

Line rate transport

Carries 10 Gigabit Ethernet traffic at full line rate.

300m

OM3 fiber reach

Reaches 300 meters over OM3 multimode cable and 400 meters over OM4.

850nm

Multimode wavelength

A VCSEL drives the transmit side and a PIN detector handles the receive side.

1.5W

Low power draw

Each module stays at or below 1.5 watts and adds little heat to the switch.

35g

Compact body

The 56.5 x 13.5 x 8.5 mm housing fits dense port rows.

70°C

Wide operating range

Runs continuously between 0 °C and 70 °C.

DAILY USE

Field swapThe module goes into the SFP+ cage by hand, and a technician replaces it without powering the switch down.

Remote monitoringDDM/DOM reports optical power and module temperature to the management interface.

Standards complianceMeets IEEE 802.3ae, SFF-8431 and the SFP+ MSA, and complies with RoHS.

Usage AreasCampus network aggregation layer·Medium-sized network core·Server cluster access·Short-reach fiber inside the data center

Reach depends on the fiber type: 300 m over OM3 cable and 400 m over OM4.

General Specifications
Model	XG-SFP-SR-MM850
Product Type	10GBASE-SR SFP+ Optical Transceiver Module
Data Rate	10.3125 Gbps
Form Factor	SFP+
Connector Type	Duplex LC
Cable Type	MMF (Multimode Fiber)
Fiber End Face Finish	Ultra Physical Contact (UPC)
Transmitter Type	VCSEL
Receiver Type	PIN
Reach	300 m (984.25 ft., with OM3 optical cables); 400 m (1312.34 ft., with OM4 optical cables)
Bit Error Ratio (BER)	1.00E-12
Digital Optical Monitoring (DDM/DOM)	Yes
Power Consumption	≤ 1.5 W
Transmitter Optical Parameters
Wavelength	850 nm
Max. Transmit Power (AVG)	–1 dBm
Min. Transmit Power (AVG)	–7.3 dBm
Min. Extinction Ratio	≥ 3.0 dB
Receiver Optical Parameters
Receive Sensitivity (OMA)	< –11.1 dBm
Overload Optical Power (AVG)	–1 dBm
Environment and Reliability
Operating Temperature	0°C to 70°C (32°F to 158°F)
Operating Humidity	10% RH to 90% RH
Storage Temperature	–40°C to +85°C (–40°F to +185°F)
Storage Humidity	10% RH to 90% RH
Dimensions and Weight
Dimensions (W × D × H)	56.5 mm x 13.5 mm x 8.5 mm (2.22 in. x 0.53 in. x 0.33 in.)
Weight	35 g (0.08 lbs.)
Standards
Standards Compliance	IEEE 802.3ae, SFF-8431, SFP+ Multisource Agreement (MSA), RoHS

●Aggregation layer of a large network, core layer of medium-sized network, access of a server cluster, and full Gigabit Layer 3 access of buildings in large enterprise or campus networks.

●The 4 fixed 10G BASE-X ports upgrade the network to a 10G uplink backbone to protect user investment.

●Strong security management mechanisms provide network security defense, high-security access control, and effective network access control.

●Superior management policies facilitate bandwidth management and ensure the performance of key applications such as voice/video conference, music and video streaming and Video on Demand (VoD).

Typical Application 1

As the aggregation layer switch of large campus network, RG-S5750-H Series Switches offers high-performance bandwidth link with 10G aggregation to core and higher bandwidth for the access device to meet the growing demand of user traffic.

Typical Application 2

The RG-S5750-H Series Switches can be deployed as core switches in small and medium enterprises. The VSU technology not only simplifies the network architecture, but also significantly improve the reliability and efficiency of the network system.
