An EP Series male metal loudspeaker cable connector. Its black finished diecast zinc alloy shell terminates professional sound reinforcement lines. It carries 20 A and solders wire up to 12 AWG.
20A
Current capacity for the speaker line
Carries the amplifier output through to the loudspeaker cabinet.
4poles
Multi conductor connection
Terminates four conductors together in one shell.
12AWG
Solder termination
Solders heavy stranded loudspeaker cable.
1000cycles
Mating durability
Withstands repeated plugging and unplugging cycles.
86mm
Overall shell length
The reference length gives cable route planning a figure to work from.
IP40rating
Closed metal shell
The shell protects the contacts in stage and studio environments.
