    Hand Held Metal Detector
    Dahua

    Hand Held Metal Detector

    Stock Code: ISC-H001

    Finds metal in spot checks with a hand-held body
    The hand-held detector carries a 420 mm × 90 mm × 45 mm body and weighs 690 g. It switches between 2 sensitivity levels at a working frequency of about 25 KHz. It signals an alarm by sound, light or vibration, which suits spot checks after a walk-through screening.
    420 × 90 × 45 mmOverall Exterior Size
    690 gNet Weight
    9 VBattery
    0.27 WPower Consumption
    25 KHzWorking Frequency
    2Sensitivity Levels
    Key features
    Triple alarmSignals metal by sound, light or vibration.
    Separate alarm controlTurns the sound alarm and the vibration alarm on and off independently.
    Two sensitivity levelsSwitches between 2 steps to suit small or large metal objects.
    Battery poweredRuns on a 9 V battery or a rechargeable cell, and 0.27 W consumption extends battery life.
    Light bodyAt 690 g the unit reduces fatigue during long hand searches.
    Wide operating temperatureWorks between –20°C and +55°C.
    General
    Overall Exterior Size420 mm × 90 mm × 45 mm (16.5" × 3.5" × 1.8")
    Packing Size445 mm × 265 mm × 520 mm (17.5" × 10.4" × 20.5")
    Net Weight690 g (1.5 lb) (without battery)
    Gross Weight920 g (2.0 lb) (with battery)
    Operating Voltage6F22/15F8H 9V battery or rechargeable battery
    Power Consumption0.27 W
    Operating Temperature–20°C ~ +55°C (–4°F ~ +131°F)
    Operating Humidity0% ~ 95%
    Storage Temperature–20°C ~ +70°C (–4°F ~ +158°F)
    Storage Humidity0% ~ 95% RH
    Working FrequencyAbout 25 KHz
    Port
    Power6F22/15F8H 9V battery or rechargeable battery
    Certification
    CertificationGB12899-2018
    IEC 60068-2-1
    IEC 60068-2-2
    CE-LVD: EN62368-1
    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
    FCC: 47 CFR FCC Part 15, Subpart B
