Physical Ports
10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX 2
Fiber Ports Number 1
Fiber Ports Standard 100Base -FX
Fiber Mode Single-mode
Fiber Diameter (μm) 62.5/125 μm 50/125 μm
Fiber Optical Connector SC
Typical Distance (km) 2 km
Wavelength (nm) 1340 dBm
Max. Output Optical Power (dBm) -14 dBm
Min. Output Optical Power (dBm) -31 dBm
Max. Input Optical Power(Saturation) 0 dBm
Min. Input Optical Power(Sensitivity) -31 dBm
Link Budget (dB) 7.5 dB
WLAN interface
Ethernet Standards IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX
LED Indicators
10/100Base-T(X) RJ45 Port Indicator Green : Power LED x 2
100Base-FX Fiber Port Indicator Green for port Link/Act. Amber for Duplex/Collision
Power
Redundant Input Power Dual 12~48 VDC power input at 4-pin terminal block
Power Consumption (Typ.) 4.5 Watts
Overload Current Protection Present
Reverse Polarity Protection Present
Physical Characteristics
Enclosure IP-30
Dimensions (W x D x H) 26.1 (W) x 70 (D) x 95 (H)mm (1.03 x 2.76 x 3.74 inch)
Weight (g) 210 g
Environmental
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Temperature -40 to 70°C (-40 to 158°F)
Operating Humidity 5% to 95% Non-condensing
Regulatory Approvals
EMI FCC Part 15, CISPR (EN55022) class A,
EMS EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
Shock IEC60068-2-27
Free Fall IEC60068-2-32
Vibration IEC60068-2-6
Safety EN60950-1
Warranty 5 years
