| Camera |
|---|
| Image Sensor | 1/1.8" STARVIS™ CMOS |
| Effective Pixels | 2592(H) × 1520(V), 4 Megapixels |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/1 s ~ 1/30,000 s |
| Minimum Illumination | Color: 0.002 Lux@F1.4; B/W: 0.0002 Lux@F1.4; 0 Lux@F1.4 (IR on) |
| S/N Ratio | More than 56 dB |
| IR Distance | Distance up to 450 m (1476 ft) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 10 |
| Smart Wiper | Support |
| Lens |
|---|
| Focal Length | 5.6 mm ~ 223 mm |
| Max. Aperture | F1.4 ~ F4.8 |
| Angle of View | H: 63.9° ~ 2.0°; V: 37.3° ~ 1.1°; D: 71.6° ~ 2.3° |
| Optical Zoom | 40x |
| Focus Control | Auto / Manual |
| Iris Control | Auto / Manual |
| Close Focus Distance | 100 mm ~ 1000 mm |
| DORI Distance |
|---|
| Note: The DORI distance is a "general proximity" of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. |
| Detect | Observe | Recognize | Identify |
|---|
| 2933 m (9623 ft) | 1164 m (3819 ft) | 586 m (1922 ft) | 293 m (961 ft) |
|
| PTZ |
|---|
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -30° ~ 90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1° ~ 240°/s; Tilt: 0.1° ~ 100°/s |
| Preset Speed | Pan: 240°/s; Tilt: 120°/s |
| Presets | 300 |
| PTZ Mode | 5 Pattern, 8 Tour (up to 32 preset per tour), Auto Pan, 5 Auto Scan |
| Speed Setup | Human-oriented focal length / speed adaptation |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Idle Motion | Activate Preset / Scan / Tour / Pattern if there is no command in the specified period |
| Protocol | DH-SD, Pelco-P/D (Auto recognition) |
| Intelligence |
|---|
| Event Trigger | Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly |
| Auto Tracking | Support |
| IVS | Tripwire, Intrusion, Abandoned/Missing |
| Advanced Intelligent Functions | Face Detection, Heat Map |
| Video |
|---|
| Compression | H.265+/H.265/H.264+/H.264/MJPEG (Sub Stream) |
| Streaming Capability | 3 Streams |
| Resolution | 4M(2592×1520)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) |
| Frame Rate | Main stream: 4M/3M (1~25/30 fps), 1080P/1.3M/720P (1~50/60 fps); Sub stream 1: D1/CIF (1~25/30 fps); Sub stream 2: 1080P/1.3M/720P (1~25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.265/H.264: 512K ~ 8192 Kbps |
| Day/Night | Auto (ICR) / Color / B/W |
| Backlight Compensation | BLC / HLC / WDR (120 dB) |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | Ultra DNR (2D/3D) |
| Motion Detection | Support |
| Region of Interest | Support |
| Electronic Image Stabilization (EIS) | Support |
| Optical Defog | Support |
| Digital Zoom | 16x |
| Flip | 180° |
| Privacy Masking | Up to 24 areas |
| Audio |
|---|
| Compression | G.711a/G.711mu/PCM/G.726/AAC/G722.1/G.729/MPEG2-Layer2 |
| Network |
|---|
| Ethernet | RJ-45 (10Base-T/100Base-TX) |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
| Interoperability | ONVIF Profile S&G, API |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 20 users |
| Edge Storage | NAS (Network Attached Storage), Local PC for instant recording, Micro SD card 256 GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, DMSS |
| Smart Phone | iOS, Android |
| Certifications |
|---|
| Certifications | CE: EN55032/EN55024/EN50130-4; FCC: Part15 subpart B, ANSI C63.4-2014; UL: UL60950-1+CAN/CSA C22.2, No.60950-1 |
| Interface |
|---|
| Video Interface | 1 port (BNC, 1.0V[p-p], 75Ω) |
| RS485 | 1 |
| Audio I/O | 1/1 |
| Alarm I/O | 7/2 |
| Electrical |
|---|
| Power Supply | AC24V/3A (±25%), Hi-PoE |
| Power Consumption | 26 W, 38 W (IR on, Heater on) |
| Environmental |
|---|
| Operating Conditions | -40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | N/A |
| Construction |
|---|
| Casing | Metal |
| Dimensions | Φ262 (mm) × 415.6 (mm) |
| Net Weight | 8.5 kg (18.74 lb) |
| Gross Weight | 14.3 kg (31.53 lb) |
