| Camera |
| Image Sensor |
1/2.8" CMOS |
| Pixel |
4 MP |
| Max. Resolution |
2560 (H) × 1440 (V) |
| ROM |
4 GB |
| RAM |
1 GB |
| Electronic Shutter Speed |
1/1 s – 1/30,000 s |
| Scanning System |
Progressive |
| Min. Illumination |
Color: 0.005 Lux@F1.6; B/W: 0.0005 Lux@F1.6; 0 Lux@F1.6 (IR on) |
| Illumination Distance |
250 m (820.21 ft) |
| Illuminator On/Off Control |
Zoom Prio; Manual; Smart IR; Off |
| Illuminator Number |
6 (IR) |
| Lens |
| Focal Length |
3.95 mm – 177.75 mm |
| Max. Aperture |
F1.6 – F4.95 |
| Field of View |
H: 70.3° – 1.8°; V: 37° – 1°; D: 69.3° – 2° |
| Optical Zoom |
45× |
| Focus Control |
Auto / Semi-Auto / Manual |
| Close Focus Distance |
0.1 m – 1 m (0.33 ft – 3.28 ft) |
| Iris Control |
Auto / Manual |
| DORI Distance |
| Lens | Detect | Observe | Recognize | Identify |
|---|
| 45× | 3,555 m (11,663.39 ft) | 1,404.2 m (4,606.96 ft) | 711 m (2,332.68 ft) | 355.5 m (1,166.34 ft) |
|
| PTZ |
| Pan/Tilt Range |
Pan: 0° to 360° endless; Tilt: –20° to +90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1°/s – 300°/s; Tilt: 0.1°/s – 200°/s |
| Preset Speed |
Pan: 400°/s; Tilt: 300°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Idle Motion |
Pattern; Preset; Scan; Tour |
| PTZ Protocol |
DH-SD; Pelco-P/D (auto recognition) |
| Intelligence |
| Video Metadata |
Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them. |
| IVS (Perimeter Protection) |
Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
| Face Detection |
Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; supports attributes extraction — 6 attributes and 8 expressions: gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; supports face cutout: face, one-inch photo; capturing strategies include real-time capturing, optimization, and quality first. |
| Construction Detection |
Detects 6 helmet colors: red, orange, yellow, blue, white and black. An alarm is triggered when a person is not wearing a helmet or when the helmet color does not match the configured color. It also supports compliance detection for work uniforms: up to 5 sample libraries can be uploaded, together containing up to 1,000 images (images must be 1080p and in JPG format); an alarm is triggered when the similarity between the detected uniform and the library samples is below the set threshold. The system detects uniform attributes such as uniform color and whether the person is wearing a mask and shoe covers, and triggers an alarm when requirements are not met. It also triggers alarms when only one person is in the construction site and when no one is present in the detection area (such as when a worker leaves their post). |
| Auto Tracking |
Yes |
| SMD |
SMD 4.0 |
| Acupick |
Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. |
| Auto Patrol |
It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
| Video |
| Video Compression |
H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Streaming Capability |
3 streams |
| Resolution |
4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) |
| Video Frame Rate |
Main stream: 4M/3M/1080p/1.3M/720p (1 – 25/30 fps); Sub stream 1: D1/VGA/CIF (1 – 25/30 fps); Sub stream 2: 1080p/1.3M/720p (1 – 25/30 fps) |
| Bit Rate Control |
CBR / VBR |
| Video Bit Rate |
H.264: 96 kbps – 14,848 kbps; H.265: 38 kbps – 8,960 kbps |
| Day/Night |
Auto (ICR) / Color / B/W |
| BLC |
Yes |
| WDR |
120 dB |
| HLC |
Yes |
| White Balance |
Auto; Indoor; Outdoor; ATW; Manual; Sodium Lamp; Natural Light; Street Lamp |
| Gain Control |
Auto / Manual |
| Noise Reduction |
2D / 3D |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Electronic (EIS) |
| Defog |
Electronic |
| Digital Zoom |
16× |
| Image Rotation |
180° |
| Privacy Masking |
Up to 24 areas can be set, with up to 8 areas in the same view |
| S/N Ratio |
≥ 55 dB |
| Audio |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Network |
| Network Port |
1 × RJ-45 (10/100 Base-T) |
| Network Protocol |
FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; QoS; RTSP; ARP |
| Interoperability |
CGI; SDK; ONVIF (Profile S&G&T); P2P |
| Streaming Method |
Unicast / Multicast |
| User/Host |
20 (total bandwidth: 64 Mbps) |
| Storage |
Micro SD card (up to 512 GB); FTP; NAS |
| Browser |
IE 9 and later; Chrome 41 and later; Firefox 50 and later; iOS 10 and later |
| Management Software |
DSS; DMSS |
| Mobile Client |
iOS; Android |
| Certification |
| Certifications |
CE: EN55032 / EN55024 / EN50130-4; FCC: Part15 subpartB, ANSI C63.4-2014 |
| Port |
| Analog Output |
1 channel (CVBS output, BNC) |
| RS-485 |
1 (bit range: 1200 bps – 9600 bps) |
| Audio Input |
1 channel |
| Audio Output |
1 channel |
| Alarm Linkage |
Capture; recording; send email; preset; tour; pattern; alarm digital output |
| Alarm Event |
Motion / Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Alarm I/O |
7 / 2 |
| Audio I/O |
1 / 1 |
| Power |
| Power Supply |
24 VDC, 2.5 A ± 25%; PoE+ (802.3at) |
| Power Consumption |
Basic: 13 W; Max: 25 W |
| Environment |
| Operating Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity |
≤ 95% (RH) |
| Protection |
IP67; IK10; TVS 6000V lightning proof; surge protection; voltage transient protection |
| Structure |
| Product Dimensions |
337.4 mm × Φ209 mm (13.28" × Φ8.23") |
| Net Weight |
5.9 kg (13.00 lb) |
| Gross Weight |
9.6 kg (21.16 lb) |
