Artikelnummer: IPMPGI-1032
| Basic | |
|---|---|
| Display Screen | LED (display in red, green and yellow) |
| Display Screen Dimensions | 976 mm × 244 mm (38.43" × 9.61") (L × W) |
| Display Contents | English letters, Chinese characters, numbers and arrows |
| Pixels Configuration | 1R1PG |
| Screen Resolution | 4,096 dots (128 × 32, 8 English letters per line), dot splicing: 7.62 mm (0.3") |
| Display Screen Lifespan | 100,000 h |
| Brightness | 1000 cd/m² |
| Port | |
| Network Port | 1 × 100 Mbps RJ-45 Ethernet port |
| General | |
| Power Supply | 100–240 VAC |
| Power Consumption | <40 W |
| Operating Temperature | –30 °C to +55 °C (–22 °F to +131 °F) |
| Storage Temperature | –35 °C to +60 °C (–31 °F to +140 °F) |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Storage Humidity | 10%–90%, non-condensing |
| Protection | IP50 |
| Product Dimensions | 1,245 mm × 65 mm × 277 mm (49.02" × 2.56" × 10.91") (L × W × H) |
| Packaging Dimensions | 1,365 mm × 370 mm × 195 mm (53.74" × 14.57" × 7.68") (L × W × H) |
| Net Weight | 8.5 kg (18.74 lb) |
| Gross Weight | 10.2 kg (22.49 lb) |
| Installation | Ceiling mount |
