Made for DIN-rail cabinets, this managed switch powers cameras and access points over 6 gigabit PoE ports, while 4 optical ports carry the fiber backbone. It runs from -40 °C to 75 °C and the IP40 metal enclosure keeps dust out. Dual power inputs keep the unit alive when one supply drops.
6 × 10/100/1000 Base-TPoE ports
120 WPoE Budget
802.3at, Hi-PoE and 802.3afPoE Protocol
28 GbpsSwitching Capacity
-40 °C to 75 °COperating Temperature
DC 9 ~ 57 VPower supply
PoE powerDelivers up to 30 W per port, and ports 1 and 2 reach 60 W in Hi-PoE mode.
Serial interfacesOne RS232 console and 2 × RS485 ports run at 9600 baud.
Dual power inputBoth inputs accept DC 9 ~ 57 V, while PoE output needs 48-57 V.
Lightning protectionWithstands 6 kV in common mode and 4 kV in differential mode.
Network redundancySTP, RSTP and MSTP bring a backup path into service when a link breaks.
ManagementSupports Web, SNMP and CLI management.
