Stock Code: ST10000VE0008
| General Specifications | |
|---|---|
| Capacity | 10 TB |
| Standard Model Number | ST10000VE0008 |
| Form Factor | 3.5 in |
| Interface | SATA 6 Gb/s |
| Recording Technology | CMR |
| Drive Design | Helium |
| Features and Performance | |
| Drive Bays Supported | 16+ |
| AI Streams | 32 |
| Real-Time AI Event Capture (per sec.) | Max. 120 |
| Real-Time AI Event Comparison (per sec.) | Max. 96 |
| HD Camera Support | Max. 64 |
| RV (Rotational Vibration) Sensors | Yes |
| Max. Sustained Data Transfer Rate (OD) | 250 MB/s |
| Cache | 256 MB |
| Reliability / Data Integrity | |
| Blackout Resilient | Yes |
| Load/Unload Cycles | 300,000 |
| Nonrecoverable Read Errors, Max. | 1 per 10E15 |
| Power-On Hours per Year | 8,760 |
| Workload Rate Limit (WRL) | 550 TB/year |
| Mean Time Between Failures (MTBF) | 2,000,000 hr |
| Rescue Data Recovery Services | 3 years |
| Power Management | |
| Startup Current, Typical (12 V) | 1.8 A |
| Average Operating Power | 6.9 W |
| Idle Average | 4.9 W |
| Standby Mode / Sleep Mode, Typical | 1.2 / 1.2 W |
| Voltage Tolerance (5 V) | ±5% |
| Voltage Tolerance (12 V) | ±10% |
| Environmental / Temperature | |
| Operating (ambient, min.) | 5°C |
| Operating (drive case, max.) | 70°C |
| Nonoperating (ambient, min.) | -40°C |
| Physical | |
| Height (max.) | 26.11 mm / 1.028 in |
| Width (max.) | 101.85 mm / 4.01 in |
| Depth (max.) | 146.99 mm / 5.787 in |
| Weight (typical) | 690 g / 1.521 lb |
