Hardware Specification |
|
Output Power Port |
12 |
|
Input Power Port |
1 |
|
Network Connector |
1 x RJ-45 port for 10/100Base-TX |
|
Console Port |
1 x RS-232 RJ-45 serial port |
|
Digital Output |
2 |
|
Daisy chaining Port |
2 x USB 2.0 |
|
Daisy chaining mode |
Auto / Manual |
|
Button |
Reset |
|
LED |
Output Power : ON / OFF
Input status indicator : Volts/Amps/Hz/Error code and daisy chained IPM |
|
Power Distribution |
|
AC Input |
200~240V, 16A, 50~60Hz |
|
AC Output |
200~240V, 50~60Hz |
|
Load |
Max. 10Amp each outlet or Max. 10Amp total for Outlet A~C. Same as D~F, G~I, J~L |
|
Inlet Connector |
1 x IEC320 C20 |
|
Outlet Connector |
12 x IEC320 C13 |
|
Management |
|
User Account |
10 |
|
Management Utility |
Web Browser, SNMP software, Windows base utility, Telnet, Hyper Terminal (via console) |
|
Security |
IP filter / Secure 128-bit SSL encryption |
|
Standards Conformance |
|
Computer Interface |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX |
|
Regulation Compliance |
CE, FCC |
|
System Unit |
|
Operating Temperature |
0 ~ 40 Degree C |
|
Operating humidity |
10% ~ 80% |
|
Dimension (W x D x H) |
436 x 300 x 44 mm |
|
Weight |
4.2kg |
|
Installation |
1U |
