Powers PoE cameras and manages the network from a web interface
This managed PoE switch powers cameras and access points over 16 ports at 10/100 Mbps, while two gigabit ports handle the uplink. A total budget of 250 W delivers up to 30 W per port. The web interface manages VLAN, STP/RSTP and IGMP Snooping settings.
16 × 10/100 Base-TPoE ports
250 WPoE Budget
802.3af and 802.3atPoE Protocol
24.8 GbpsSwitching Capacity
-10 °C to 55 °COperating Temperature
AC 100 ~ 240 VPower supply
Key features
PoE powerDelivers up to 30 W per port and up to 250 W in total.
Network redundancySTP and RSTP shut down a looping link and bring the backup path into service.
VLAN separationPort-based VLAN and 802.1Q tagging keep camera traffic apart from the rest.
SecurityHolds IP and MAC binding at port level and supports 802.1x authentication.
Web managementThe http and https interface uploads and downloads the configuration file and keeps system logs.
Mains inputConnects straight to an AC 100 ~ 240 V supply with no separate adapter.
