Stock Code: HDMI1408S


| HDMI Extender - Technical Specifications | |
|---|---|
| HDMI Version | HDMI 1.4 with HDCP 1.4 support |
| 3D Video Support | Supports 3D video formats |
| CEC Support | Consumer Electronics Control (CEC) supported |
| Maximum Resolution | 3840x2160p @ 45Hz |
| Bandwidth & TMDS | 6G max rate, TMDS up to 600 MHz |
| Color Depth | 8/10/12-bit Deep Color per channel |
| HDMI Cable Support | 26 AWG HDMI cable: - Up to 8 m for input and output at 1080p or lower - Up to 8 m for input and output at 4K resolution |
| Source & Output | Single HDMI source port, multiple HDMI outputs; source can be DVD player, A/V receiver, or set-top box |
| IR Extension | Supports remote source control via IR-RX HDMI repeater |
| Serial Port | Online development support |
| EDID Management | Supported |
| Power Adapter | 5V / 3A |
