Name: 2 Pin Speakon Connector
Brand: Amphenol
SKU: SP-2-F

Terminates a single speaker line on two contacts

An SP series loudspeaker connector plug that carries a single speaker line over two contacts. The black plastic housing grips the cable at the rear with a standard nut clamp.

2Pin Count

Screwtermination

Standard nutcable clamp

Ø 28.0 mmbody diameter

RoHScompliance

Key features

Screw terminationScrew terminals clamp the conductors reaching the two contacts.

Standard nutThe nut at the rear of the housing tightens onto the cable.

Straight cable exitThe cable leaves the rear in line with the housing body.

Plastic housingThe black shell measures 28.0 mm across and the nut is black as well.

RoHS complianceThe product complies with directive 2002/95/EC.

General

Product Type

Loudspeaker Connector Plug

Series

Part Number

SP-2-F

Manufacturer

Amphenol Australia Pty. Ltd.

Construction & Configuration

Number of Contacts (Poles)

Type

Cable Straight (F)

Shell Finish

Plastic, Black

Termination

Screw

Clamp Option

Standard Nut

Nut Colour

Black

Packaging

Bags

Mechanical

Body Diameter

Ø28.0 mm

Compliance

RoHS

Compliant (2002/95/EC)

Terminates a single speaker line on two contacts

An SP series loudspeaker connector plug that carries a single speaker line over two contacts. The black plastic housing grips the cable at the rear with a standard nut clamp.

2Pin Count

Screwtermination

Standard nutcable clamp

Ø 28.0 mmbody diameter

RoHScompliance

Key features

Screw terminationScrew terminals clamp the conductors reaching the two contacts.

Standard nutThe nut at the rear of the housing tightens onto the cable.

Straight cable exitThe cable leaves the rear in line with the housing body.

Plastic housingThe black shell measures 28.0 mm across and the nut is black as well.

RoHS complianceThe product complies with directive 2002/95/EC.

2 Pin Speakon Connector

Options

Teknik Çizim

SP-2-F
