Records long corridors and passages at a fixed angle

A 1/2.7 inch 2MP CMOS sensor produces images at 1920×1080. The fixed 3.6 mm lens gives an 87.5° horizontal field of view, and 12 IR LEDs light the scene up to 20 m in darkness.

1920×1080Max. resolution

1/2.7 inch CMOSImage sensor

3.6 mmFixed lens

20 mMax. IR distance

IP67Protection grade

12 V DCPower

Key features

Low light performanceIt produces color images at 0.02 Lux and keeps recording at 0 Lux with IR on.

Frame rateIt records at 25/30 fps in 1080P and at 50/60 fps in 720P.

DORI distancesWith the 3.6 mm lens it detects at 53 m, observes at 21 m and recognizes at 11 m.

Smart IRThe 12 IR LEDs run in auto or manual mode, and Smart IR balances brightness on nearby objects.

Outdoor durabilityIt carries IP67 protection and runs between -40°C and +60°C at less than 90% relative humidity.

Power drawIt runs on a 12V DC ±25% supply range and draws a maximum of 3.2 W with IR on.

Camera

Image Sensor

1/2.7" CMOS

Effective Pixels

1920(H)×1080(V), 2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s

Minimum Illumination

0.02Lux/F2.0, 30IRE, 0Lux (IR on)

S/N Ratio

More than 65dB

IR Distance

Up to 20m (66feet)

IR On/Off Control

Auto / Manual

IR LEDs

Lens

Lens Type

Fixed lens / Fixed iris

Mount Type

Board-in

Focal Length

3.6mm (6mm optional)

Max. Aperture

F2.0

Angle of View

H: 87.5°(54.7°)

Focus Control

N/A

Close Focus Distance

900mm (2000mm)
35.43'' (78.74'')

DORI Distance

DORI	Definition	3.6mm	6mm
Detect	25px/m (8px/ft)	53m(175ft)	80m(262ft)
Observe	63px/m (19px/ft)	21m(70ft)	32m(105ft)
Recognize	125px/m (38px/ft)	11m(35ft)	16m(52ft)
Identify	250ppm (76px/ft)	5m(17ft)	8m(26ft)

DORI Note

The DORI distance is a "general proximity" of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.

Pan / Tilt / Rotation

Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotation: 0° ~ 360°

Video

Resolution

1080P (1920×1080)

Frame Rate

25/30fps@1080P, 25/30/50/60fps@720P

Video Output

1-channel BNC high definition video output / CVBS video output (can switch)

Day/Night

Auto (ICR) / Manual

OSD Menu

Multi-language

BLC Mode

BLC / HLC / DWDR

WDR

DWDR

Gain Control

AGC

Noise Reduction

White Balance

Auto / Manual

Smart IR

Auto / Manual

Certifications

EN55032, EN55024, EN50130-4

FCC

CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014

UL60950-1+CAN/CSA C22.2 No.60950-1

Interface

Audio Interface

N/A

Electrical

Power Supply

12V DC ±25%

Power Consumption

Max. 3.2W (12V DC, IR on)

Environmental

Operating Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
* Start up should be done at above -40°C (-40°F)

Storage Conditions

-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

Ingress Protection & Vandal Resistance

IP67

Construction

Casing

Plastic

Dimensions

154.3mm×69.8mm×69.8mm (6.07"×2.75"×2.75")

Net Weight

0.20kg (0.44lb)

Gross Weight

0.27kg (0.60lb)
