| Camera |
|---|
| Image Sensor | 1/1.8" CMOS |
| Pixel | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Electronic Shutter Speed | 1/3 – 1/30,000 s |
| Scanning System | Progressive Scanning |
| Min. Illumination | Color: 0.001 Lux@F1.6; B/W: 0.0001 Lux@F1.6; 0 Lux (IR light on) |
| Illumination Distance | 150 m (492.13 ft) |
| Illuminator Control | Zoom Prio/Manual/SmartIR |
| Illuminator Number | 4 |
| Lens |
|---|
| Focal Length | 5.4 mm – 135 mm |
| Max. Aperture | F1.6 – F4.0 |
| Field of View | H: 61.6°–3.6°; V: 35.7°–2°; D: 66.6°–4° |
| Optical Zoom | 25× |
| Focus Control | Auto/Semi-Auto/Manual |
| Close Focus Distance | 0.1 m – 2 m |
| Iris Control | Auto/Manual |
| DORI Distance | | Detect | Observe | Recognize | Identify |
|---|
| 1724 m (5656.16 ft) | 689 m (2260.50 ft) | 344 m (1128.61 ft) | 172 m (564.30 ft) |
|
| PTZ |
|---|
| Pan/Tilt Range | Pan: 0°–360°; Tilt: -15°–+90° |
| Manual Control Speed | Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s |
| Preset Speed | Pan: 400°/s; Tilt: 300°/s |
| Presets | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Speed Adjustment | Support |
| Power-off Memory | Support |
| Idle Motion | Preset/Tour/Pattern/Scanning |
| Protocol | DH-SD; Pelco-P/D (Auto Recognition) |
| General Intelligence |
|---|
| Event Trigger | Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly |
| IVS | Object Abandoned/Missing |
| Artificial Intelligence |
|---|
| Smart Capture | Support human, motor vehicle and non-motor vehicle image capture |
| Perimeter Protection | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| SMD PLUS | Support |
| Auto Tracking | Support |
| Face Detection | Support |
| Video |
|---|
| Compression | H.265/H.265+/H.264+/H.264/MJPEG (Sub Stream) |
| Streaming Capability | 3 Streams |
| Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 720p (1280 × 960); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate | Main stream: 4M/3M (1–25/30 fps), 1080p/1.3M/720p (1–25/30 fps); Sub stream 1: D1/CIF (1–25/30 fps); Sub stream 2: 1080p/1.3M/720p (1–25/30 fps), D1/CIF (1–25/30 fps) |
| Bit Rate Control | Variable/Constant |
| Bit Rate | H.264: 32 Kbps–8192 Kbps; H.265: 32 Kbps–8192 Kbps |
| Day/Night | Support |
| BLC | Support |
| WDR | 120 dB |
| HLC | Support |
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium Lamp/Natural/Street Lamp |
| Gain Control | Auto/Manual |
| Noise Reduction | 2D/3D |
| Motion Detection | Support |
| Region of Interest (RoI) | Support |
| Image Stabilization | Electronic |
| Defog | Support |
| Digital Zoom | 16× |
| Flip | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view |
| Certification |
|---|
| Certifications | CE: EN55032/EN55024/EN50130-4; FCC: Part15 Subpart B, ANSI C63.4-2014; UL: UL60950-1 + CAN/CSA 22.2 No.60950-1 |
| Audio |
|---|
| Audio Compression | G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2 |
| Port |
|---|
| Audio I/O | 1 (Line in; bare wire)/1 (Line out; bare wire) |
| Alarm I/O | 2 alarm input ports; 1 alarm output port |
| Network |
|---|
| Ethernet | 1 RJ-45 port (10/100Base-T) |
| Protocol | IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP; RTMP |
| Interoperability | ONVIF Profile S&G&T; CGI |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth 48 Mbps) |
| Storage | FTP; Micro SD card (256 GB); P2P |
| Browser | IE7 and newer versions; Chrome 42 and older versions; Firefox 52 and older versions; Safari |
| Management Software | Smart Player; Smart PSS; DSS; Easy4ip |
| Mobile Phone | iOS; Android |
| Power |
|---|
| Power Supply | DC 24 V/2.5 A (±25%); PoE+ (802.3at) |
| Power Consumption | 11 W; 20 W (IR light on) |
| Environment |
|---|
| Operating Conditions | –40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity | ≤ 95% RH |
| Protection | IP67; IK10; TVS 6000 V lightning protection; surge protection |
| Structure |
|---|
| Dimensions | Φ190 mm × 332 mm (7.48" × 13.07") |
| Weight | Net Weight: 4.7 kg (10.36 lb); Gross Weight: 8 kg (17.64 lb) |
| Casing | Metal |
