Stock Code: SDT6C432-4P-GB-APV-0280
| Camera | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Image Sensor | Panorama: 1/2.8" CMOS Detail: 1/2.8" CMOS | ||||||||
| Effective Pixels | Panorama: 4 MP Detail: 4 MP | ||||||||
| Max. Resolution | Panorama: 3840 (H) × 1080 (V) Detail: 2560 (H) × 1440 (V) | ||||||||
| ROM | Panorama: 4 GB Detail: 4 GB | ||||||||
| RAM | Panorama: 1 GB Detail: 1 GB | ||||||||
| Electronic Shutter Speed | Panorama: 1/1 s – 1/10,000 s Detail: 1/1 s – 1/30,000 s | ||||||||
| Scanning System | Progressive | ||||||||
| Min. Illumination | Panorama: Color: 0.001 lux@F1.0 B/W: 0.0001 lux@F1.0 Detail: Color: 0.005 lux@F1.6 (1/25 s, 30 IRE, gain 100) B/W: 0.0005 lux@F1.6 (1/25 s, 30 IRE, gain 100) 0 lux (IR on) | ||||||||
| IR/Illumination Distance | Panorama: 30 m (98.43 ft) (White light) Detail: 200 m (656.17 ft) (IR) | ||||||||
| Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off | ||||||||
| Illuminator Number | Panorama: 4 (White light) Detail: 4 (IR), 2 (White light) | ||||||||
| Lens | |||||||||
| Focal Length | Panorama: 2.8 mm Detail: 4.8 mm – 154 mm | ||||||||
| Max. Aperture | Panorama: F1.0 Detail: F1.6 – 4.0 | ||||||||
| Field of View | Panorama: H: 180° ± 5°; V: 51° Detail: H: 55.8° – 2.3°; V: 31.9° – 1.3°; D: 63.7° – 2.7° | ||||||||
| Optical Zoom | Panorama: NA Detail: 32× | ||||||||
| Focus Control | Panorama: NA Detail: Auto; semi-auto; manual | ||||||||
| Close Focus Distance | Panorama: 0.3 m (0.98 ft) Detail: 0.8 m – 5 m (2.62 ft – 16.40 ft) | ||||||||
| Iris Control | Panorama: Fixed Detail: Auto; manual | ||||||||
| DORI Distance |
| ||||||||
| PTZ | |||||||||
| Pan/Tilt Range | Detail: H: 0° – 360° endless V: –20° – +90° | ||||||||
| Manual Control Speed | Detail: Pan: 0.1°/s – 160°/s Tilt: 0.1°/s – 120°/s | ||||||||
| Preset Speed | Detail: Pan: 240°/s; Tilt: 200°/s | ||||||||
| Preset | 300 | ||||||||
| Tour | 8 (up to 32 presets per tour) | ||||||||
| Pattern | 5 | ||||||||
| Scan | 5 | ||||||||
| Power-off Memory | Yes | ||||||||
| Idle Motion | Pattern; Preset; Scan; Tour | ||||||||
| PTZ Protocol | DH-SD Pelco-P/D (Auto recognition) | ||||||||
| Intelligence | |||||||||
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking | ||||||||
| Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; supports attributes extraction (6 attributes and 8 expressions); supports face cutout (face, one-inch photo); capturing strategies include real-time capturing, optimization, and quality first | ||||||||
| Auto Tracking | Yes | ||||||||
| Active Deterrence | |||||||||
| Light Warning | Supports white light warning; the flashing time can be configured as 5 to 30 seconds, and the frequency can be configured as high/medium/low | ||||||||
| Sound Warning | A total of 11 audio alarm contents, and supports importing custom audio; the sound can be configured at three levels: high/medium/low, and the duration can be configured as 5 to 30 seconds; 110 dB | ||||||||
| Video | |||||||||
| Video Compression | H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream); Smart H.264+; H.264M | ||||||||
| Streaming Capability | 3 streams | ||||||||
| Resolution | Panorama: 3840 × 1080; 960 × 268; D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240) Detail: 2560 × 1440; 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240) | ||||||||
| Video Frame Rate | Panorama: 50 Hz Main stream (3840 × 1080@25 fps), Sub stream 1 (960 × 268@25 fps), Sub stream 1 (704 × 576@25 fps), Sub stream 1 (640 × 480@25 fps), Sub stream 1 (352 × 288@25 fps), Sub stream 2 (1920 × 540@25 fps), Sub stream 2 (1920 × 1080@25 fps), Sub stream 2 (1280 × 960@25 fps), Sub stream 2 (1280 × 720@25 fps) 60 Hz Main stream (3840 × 1080@30 fps), Sub stream 1 (960 × 268@30 fps), Sub stream 1 (704 × 576@30 fps), Sub stream 1 (640 × 480@30 fps), Sub stream 1 (352 × 288@30 fps), Sub stream 2 (1920 × 540@30 fps), Sub stream 2 (1920 × 1080@30 fps), Sub stream 2 (1280 × 960@30 fps), Sub stream 2 (1280 × 720@30 fps) Detail: 50 Hz Main stream (2560 × 1440@25 fps), Main stream (2048 × 1536@25 fps), Main stream (2304 × 1296@25 fps), Main stream (1920 × 1080@25 fps), Main stream (1280 × 960@25 fps), Main stream (1280 × 720@25 fps) Sub stream 1 (704 × 576@25 fps), Sub stream 1 (640 × 480@25 fps), Sub stream 1 (352 × 288@25 fps), Sub stream 2 (1280 × 720@25 fps) 60 Hz Main stream (2560 × 1440@30 fps), Main stream (2048 × 1536@30 fps), Main stream (2304 × 1296@30 fps), Main stream (1920 × 1080@30 fps), Main stream (1280 × 960@30 fps), Main stream (1280 × 720@30 fps) Sub stream 1 (704 × 480@30 fps), Sub stream 1 (640 × 480@30 fps), Sub stream 1 (352 × 240@30 fps), Sub stream 2 (1280 × 720@30 fps) | ||||||||
| Bit Rate Control | CBR / VBR | ||||||||
| Video Bit Rate | Panorama: H.264: 2,816 kbps – 13,824 kbps H.265: 1,024 kbps – 8,192 kbps Detail: H.264: 2,816 kbps – 13,056 kbps H.265: 1,024 kbps – 7,936 kbps | ||||||||
| Day/Night | Panorama: Auto (ICR) / Color / B/W Detail: Auto (ICR) / Color / B/W | ||||||||
| BLC | Yes | ||||||||
| WDR | Panorama: Yes Detail: Yes | ||||||||
| HLC | Yes | ||||||||
| White Balance | Panorama: Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp Detail: Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp | ||||||||
| Gain Control | Panorama: Auto / manual Detail: Auto / manual | ||||||||
| Noise Reduction | Panorama: 2D / 3D noise reduction Detail: 2D / 3D noise reduction | ||||||||
| Motion Detection | Yes | ||||||||
| Region of Interest (RoI) | Yes | ||||||||
| Image Stabilization | Electronic Image Stabilization (EIS) | ||||||||
| Defog | Panorama: Electronic Defog Detail: Electronic Defog | ||||||||
| Digital Zoom | 16× | ||||||||
| Image Rotation | 180° | ||||||||
| S/N Ratio | Panorama: ≥55 dB Detail: ≥55 dB | ||||||||
| Audio | |||||||||
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 | ||||||||
| Network | |||||||||
| Network Port | RJ-45 (10/100 Base-T) | ||||||||
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; QoS; RTSP; ARP | ||||||||
| Interoperability | CGI; ONVIF (Profile S&G&T) | ||||||||
| User/Host | 20 (total bandwidth: 64 M) | ||||||||
| Storage | FTP; Micro SD card (up to 512 GB); NAS | ||||||||
| Browser | IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions iOS 10 and later versions | ||||||||
| Management Software | DMSS; DSS Pro | ||||||||
| Mobile Client | iOS; Android | ||||||||
| Certification | |||||||||
| Certifications | CE: DHQA-ESH-P22100890 / DHQA-ESH-P22100654B-A1 | ||||||||
| Port | |||||||||
| Audio Input | 1 channel (LINE IN, bare wire) | ||||||||
| Audio Output | 1 channel (LINE OUT, bare wire) | ||||||||
| Alarm Linkage | Capture; PTZ linkage (preset; tour; pattern); recording; alarm digital input; audio; send email | ||||||||
| Alarm Event | Motion / Tampering detection; audio detection; network disconnection detection; IP conflict detection; SD card abnormal detection; memory space detection; tampering detection | ||||||||
| Alarm I/O | 2 / 1 | ||||||||
| Audio I/O | 1 / 1 | ||||||||
| Power | |||||||||
| Power Supply | 36 V DC / 2.23 A ± 25% | ||||||||
| Power Consumption | Basic power consumption: 20 W Max. power consumption: 35 W (IR + heater + intelligent functions + PTZ working) | ||||||||
| Environment | |||||||||
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) | ||||||||
| Operating Humidity | ≤95% | ||||||||
| Protection | IP66 | ||||||||
| Structure | |||||||||
| Casing Material | Plastic, aluminum alloy | ||||||||
| Product Dimensions | 247 mm × 202 mm × 359.8 mm (9.72" × 7.95" × 14.17") (L × W × H) | ||||||||
| Net Weight | 5.3 kg (11.68 lb) | ||||||||
| Gross Weight | 7.12 kg (15.70 lb) | ||||||||
