| Camera |
|---|
| Image Sensor | 1/1.8" 4 Megapixel progressive CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| RAM/ROM | 2 GB / 4 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| Min. Illumination | 0.001 lux@F1.2 (Color, 30 IRE); 0.0002 lux@F1.2 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Illumination Distance | 40 m (131.23 ft) (IR) |
| Illuminator On/Off Control | Auto |
| Illuminator Number | 3 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–355°; Tilt: 0°–80°; Rotation: 0°–355° |
| Lens |
|---|
| Lens Type | Motorized vari-focal |
| Mount Type | Module interface |
| Focal Length | 2.7 mm–12 mm |
| Max. Aperture | F1.2 |
| Field of View | Horizontal: 114°(W)–47°(T); Vertical: 59°(W)–27°(T); Diagonal: 141°(W)–55°(T) |
| Iris Type | Auto; Precise iris control |
| Close Focus Distance | W: 1 m (3.28 ft); T: 2.5 m (8.20 ft) |
| DORI Distance | | Lens | Detect | Observe | Recognize | Identify |
|---|
| W | 60.1 m (197.18 ft) | 24 m (78.74 ft) | 12 m (39.37 ft) | 6 m (19.69 ft) | | T | 128.6 m (421.92 ft) | 51.4 m (168.64 ft) | 25.7 m (84.31 ft) | 12.8 m (41.99 ft) |
|
| Intelligence |
|---|
| IVS (Perimeter Protection) | Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering |
| Face Detection | Face detection, track, priority, snapshot, upload optimized snapshot picture; face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mouth mask, beard; face matting setting; three snapshot methods: real-time snapshot, priority snapshot, quality priority; face angle filter; priority time setting; non-living filtering |
| Face Recognition | There are two modes: General mode and counting mode. General mode: face detection; track; snapshot; snapshot optimization; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); supports up to 5 face databases with 50,000 face pictures in total; supports non-living filtering. Counting mode: offers advanced customer counter, filtering of specified face database, and exporting of reports before and after removing duplicate faces |
| Face and Body Detection | There are two modes: General mode and PPE Detection. General mode: supports enabling face detection and human detection at the same time, and alarms can be triggered. PPE Detection: supports PPE detection, can detect attributes including face mask, safety helmet, glasses, safety vest, top color and bottom color, and determine whether PPE requirements are met. Alarms can be triggered according to the alarm settings |
| ANPR | ANPR, track, priority, snapshot; vehicle attributes: license plate, vehicle type, vehicle color; other attributes: seat belt, smoking, phoning |
| Video Metadata | Supports human body, human face, motor vehicle and non-motor vehicle image capture, attributes extraction, counting targets by directions (A>B, B>A, or A< >B), and exporting the report |
| People Counting | Supports tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports; supports queue management, and displaying and outputting monthly/daily reports; supports 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions |
| Intelligent Search | Work together with Smart NVR to perform refined intelligent search, event extraction and merging to event videos |
| Smart Event |
|---|
| IVS | Abandoned object, moving object |
| Video |
|---|
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+/ Smart H.264+ |
| Video Frame Rate | Main Stream: 2688 × 1520 (1–50/60 fps); Sub Stream: 704 × 576 (1–25 fps); 704 × 480 (1–30 fps); Third Stream: 1920 × 1080 (1–25/30 fps); Fourth Stream: 1920 × 1080 (1–25/30 fps); Fifth Stream: 704 × 576 (1–25 fps); 704 × 480 (1–30 fps) |
| Stream Capability | 5 streams |
| Resolution | 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 Kbps–10240 Kbps; H.265: 12 Kbps–10240 Kbps |
| Day/Night | Auto (ICR)/Color/B&W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | Off/On (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (supports 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 areas |
| Audio |
|---|
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
|---|
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception; queue management; face & body detection; face & body detection (match attributes alarm); face & body detection (mismatch attributes alarm); face recognition |
| Network |
|---|
| Network | RJ-45 (10/100/1000 Base-T) |
| SDK and API | Yes |
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P; RTMP |
| User | 20 (Total bandwidth: 80 M) |
| Storage | FTP; Micro SD card (256 G); NAS; SFTP |
| Browser | IE: IE9 and later; Chrome: Chrome 42 and later; Firefox: Firefox 48.0.2 and later |
| Management Software | Smart PSS; DSS; DMSS |
| Mobile Client | iOS, Android |
| Certification |
|---|
| Certifications | CE-LVD: EN62368-1, EN60950-22 (optional); CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07, UL 50E NEMA Type 4X (optional) |
| Port |
|---|
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) |
| Power |
|---|
| Power Supply | 12V DC/24V AC/PoE+ (802.3at); ePoE |
| Power Consumption | Basic power consumption: 5.4 W (12V DC); 5 W (24V AC); 4.9 W (PoE); Max. power consumption (max. stream + intelligent function + IR LED + focus): 16.7 W (12V DC); 15.7 W (24V AC); 15.6 W (PoE); Heat power consumption: 3.3 W (12V DC); 5.5 W (24V AC); 5.5 W (PoE) |
| Environment |
|---|
| Operating Temperature | –40°C to +60°C (–40°F to +140°F)/less than 95% RH |
| Storage Temperature | –40°C to +60°C (–40°F to +140°F)/10%–95% (RH), non-condensing |
| Protection | IP67, IK10; Anti-Corrosion Protection: NEMA 4X (optional) |
| Structure |
|---|
| Casing | Metal + Plastic |
| Dimensions | 129.1 mm × Φ157.9 mm (5.08" × Φ6.22") (L × W × H) |
| Net Weight | 1500 g (3.31 lb) |
| Gross Weight | 1600 g (3.53 lb) |
