| Camera |
|---|
| Image Sensor | 1/3" 4 Megapixel progressive CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s – 1/100000 s |
| Min. Illumination | 0.005 Lux@F1.6 (Color, 30IRE); 0.0005 Lux@F1.6 (B/W, 30IRE); 0 Lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| IR Distance | 30 m (98.4 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 8 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: -30° – 30°; Tilt: 0° – 80°; Rotation: 0° – 360° |
| Lens |
|---|
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm; 3.6 mm; 6 mm |
| Max. Aperture | F1.6 |
| Field of View | 2.8 mm: Horizontal: 103°; Vertical: 55°; Diagonal: 122°; 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°; 6 mm: Horizontal: 52°; Vertical: 28°; Diagonal: 61° |
| Iris Type | Fixed |
| Close Focus Distance | 2.8 mm: 0.9 m (3.0 ft); 3.6 mm: 1.6 m (5.3 ft); 6 mm: 3.2 m (10.5 ft) |
| DORI Distance | | Lens | Detect | Observe | Recognize | Identify |
|---|
| 2.8 mm | 56.0 m (183.7 ft) | 22.4 m (73.5 ft) | 11.2 m (36.8 ft) | 5.6 m (18.4 ft) | | 3.6 mm | 80.0 m (262.5 ft) | 32.0 m (105.0 ft) | 16.0 m (52.5 ft) | 8.0 m (26.3 ft) | | 6 mm | 120.0 m (393.7 ft) | 48.0 m (157.5 ft) | 24.0 m (78.7 ft) | 12.0 m (39.4 ft) |
|
| Professional, Intelligent |
|---|
| Perimeter Protection | Tripwire; intrusion (Recognition of human and vehicle) |
| Intelligent Search | Work together with Smart NVR to perform refined intelligent search, event extraction and merging to event videos |
| Video |
|---|
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream (2688 × 1520@1 – 25/30 fps); sub stream (704 × 576@1 – 25 fps / 704 × 480@1 – 30 fps); third stream (1280 × 720@1 – 25/30 fps) |
| Stream Capability | 3 streams |
| Resolution | 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 3 Kbps – 8192 Kbps; H.265: 3 Kbps – 8192 Kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
|---|
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; G726 |
| Alarm |
|---|
| Alarm Event | No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD |
| Network |
|---|
| Network | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
| Scene Self-adaptation (SSA) | Yes |
| User/Host | 20 (Total bandwidth: 64 M) |
| Storage | FTP; SFTP; Micro SD Card (support max. 256 G); NAS |
| Browser | IE: IE8, IE9, IE11; Chrome; Firefox |
| Management Software | Smart PSS, DSS, DMSS |
| Mobile Phone | IOS; Android |
| Certification |
|---|
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B |
| Power |
|---|
| Power Supply | 12 V DC/PoE (802.3af) |
| Power Consumption | < 5.7 W |
| Environment |
|---|
| Operating Conditions | -40°C to +60°C (-40°F to +140°F) / less than 95% humidity |
| Storage Conditions | -40°C to +60°C (-40°F to +140°F) |
| Protection Grade | IP67; IK10 |
| Structure |
|---|
| Casing | Metal |
| Dimensions | 55 mm × Φ108.9 mm (2.2" × Φ4.3") |
| Net Weight | 380 g (0.8 lb) |
| Gross Weight | 520 g (1.1 lb) |
