| Camera |
| Image Sensor |
1/3" 4 Megapixel progressive CMOS |
| Effective Pixels |
2688 (H) × 1520 (V) |
| Max. Resolution |
2688 (H) × 1520 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto / Manual; 1/3 s – 1/100000 s |
| Min. Illumination |
0.005 Lux @F1.6 |
| IR Distance |
50 m (164 ft) |
| IR On/Off Control |
Auto / Manual |
| Illuminator Number |
2 (IR LED) |
| Pan / Tilt / Rotation Range |
Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm; 6 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: Horizontal: 103°; Vertical: 55°; Diagonal: 122°; 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°; 6 mm: Horizontal: 52°; Vertical: 28°; Diagonal: 61° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 0.9 m (3.0 ft); 3.6 mm: 1.6 m (5.3 ft); 6 mm: 3.2 m (10.5 ft) |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
56 m (183.7 ft) |
22.4 m (73.5 ft) |
11.2 m (36.8 ft) |
5.6 m (18.4 ft) |
| 3.6 mm |
80 m (262.5 ft) |
32 m (105 ft) |
16 m (52.5 ft) |
8 m (26.3 ft) |
| 6 mm |
120 m (393.7 ft) |
48 m (157.5 ft) |
24 m (78.7 ft) |
12 m (39.4 ft) |
|
| Intelligence |
| Perimeter Protection |
Tripwire; Intrusion (human and vehicle recognition) |
| Smart Search |
Works with Smart NVR to perform refined search, event extraction and merging to event videos |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec |
Smart H.265+ / Smart H.264+ |
| Video Frame Rate |
Main stream: 2688 × 1520 @1–25/30 fps; Sub stream: 704 × 576 @1–25 fps / 704 × 480 @1–30 fps; Third stream: 1280 × 720 @1–25/30 fps |
| Stream Capability |
3 streams |
| Resolution |
4 MP (2688 × 1520); 3 MP (2304 × 1296); 1080p (1920 × 1080); 1.3 MP (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240) |
| Bit Rate Control |
CBR / VBR |
| Video Bit Rate |
H.264: 3 Kbps – 8192 Kbps; H.265: 3 Kbps – 8192 Kbps |
| Day/Night |
Auto (ICR) / Color / B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom |
| Gain Control |
Auto / Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
On / Off (4 rectangular zones) |
| Region of Interest (ROI) |
Yes (4 zones) |
| Smart IR |
Yes |
| Image Rotation |
0° / 90° / 180° / 270° (90°/270° supported at 1920 × 1080 resolution) |
| Mirror |
Yes |
| Privacy Masking |
4 zones |
| Audio |
| Built-in Mic |
Yes |
| Audio Compression |
G.711a; G.711Mu; G.726; AAC |
| Alarm |
| Alarm Events |
Motion detection; video tampering; scene changing; audio detection; no SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; tripwire; intrusion; SMD |
| Network |
| Network Interface |
RJ-45 (10/100 Base-T) |
| Protocols |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF (Profile S / Profile G); CGI; P2P; Milestone; Genetec |
| Scene Self-adaptation (SSA) |
Yes |
| User / Host |
20 users (Total bandwidth: 64 Mbps) |
| Edge Storage |
FTP; SFTP; Micro SD Card (max. 256 GB); Dahua Cloud; NAS |
| Supported Browsers |
IE8; IE9; IE11; Chrome; Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile App |
iOS; Android |
| Certifications |
| Certifications |
CE-LVD: EN60950-1; CE-EMC: 2014/30/EU; FCC: 47 CFR Part 15, Subpart B; UL/CUL: UL60950-1, CAN/CSA C22.2 No.60950-1-07 |
| Power |
| Power Supply |
12 V DC / PoE (802.3af) |
| Power Consumption |
< 7.7 W |
| Environment |
| Operating Conditions |
-40°C ~ +60°C (-40°F ~ +140°F) / ≤ 95% RH |
| Storage Conditions |
-40°C ~ +60°C (-40°F ~ +140°F) |
| Ingress Protection |
IP67 |
| Construction |
| Casing |
Metal |
| Dimensions |
99.1 mm × Φ121.9 mm (3.9" × Φ4.8") |
| Net Weight |
480 g (1.05 lb) |
| Gross Weight |
660 g (1.45 lb) |
