| Camera |
|---|
| Image Sensor | 1/1.8" CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto / Manual; 1/3 s – 1/100,000 s |
| Min. Illumination | 0.0006 lux@F1.2 (Color, 30 IRE); 0.0003 lux@F1.2 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| IR Distance | Up to 40 m (131.23 ft) (IR) |
| Illuminator On/Off Control | Auto; Zoom prio; Manual |
| Illuminator Number | 3 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–355°; Tilt: 0°–80°; Rotation: 0°–355° |
| Lens |
|---|
| Lens Type | Motorized vari-focal |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm – 12.0 mm |
| Max. Aperture | F1.2 |
| Field of View | H: 114°–48°; V: 59°–27°; D: 143°–56° |
| Iris Control | Auto |
| Iris Type | P-Iris |
| Close Focus Distance | 1.75 m (5.74 ft) |
| DORI Distance |
| Lens | Detect | Observe | Recognize | Identify |
|---|
| Wide (W) | 60.4 m | 24.2 m | 12.1 m | 6.0 m |
| Tele (T) | 128.7 m | 51.5 m | 25.7 m | 12.9 m |
|
| Intelligence |
|---|
| Perimeter Protection (IVS) | Intrusion, tripwire, fast moving; loitering, people gathering, parking detection; vehicle/animal/human classification; long-distance mode; false alarm filtering |
| Smart Object Detection | Abandoned object; missing object detection |
| SMD | SMD 3.0 |
| AcuPick | Deep learning algorithm; human/animal/vehicle target matching and video search |
| AI SSA | Yes |
| Face Detection | Face detection, tracking, snapshot, face enhancement, exposure, attribute extraction (6 attributes, 8 expressions), customization options, filtering |
| People Counting | Tripwire and in-area counting, queue management, reporting (day/week/month/year), 4 configurable rules |
| Heat Map | Yes |
| Video Metadata | Vehicle, non-motor vehicle, human body, face detection and attributes (color, type, accessory, etc.) |
| Smart Search | Works with Smart NVR for event analysis and video merging |
| Smart Sound Detection | Yes |
| Video |
|---|
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (sub stream only) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 2688 × 1520 (1–25/30 fps) / 1920 × 1080 (1–50/60 fps); Sub stream: D1@(1–25/30 fps); Third stream: 1080p@(1–25/30 fps); Fourth stream: 720p@(1–25/30 fps) |
| Stream Capability | 4 streams |
| Resolution | 4M, 3.6M, 3M, 1080p, 720p, D1, VGA, CIF |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps – 16384 kbps; H.265: 12 kbps – 11008 kbps |
| Day/Night | Auto (ICR) / Color / B&W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto, natural, street lamp, outdoor, manual, regional |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | ON / OFF (4 areas) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (supported at 4M resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 areas |
| LDC | Yes |
| Audio |
|---|
| Built-in MIC | Yes, dual microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
|---|
| Alarm Event | No SD card, full, error; network disconnection; IP conflict; illegal access; motion; tampering; perimeter IVS events; face, audio, data, SMD, people counting; queue management; security exception |
| Network |
|---|
| Network Port | RJ-45 (10/100 Enhanced Base-T) |
| SDK and API | Yes |
| Network Protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P, Auto Register |
| Interoperability | ONVIF (Profile S/G/T/M); CGI |
| User/Client | 20 users (total bandwidth: 80 M) |
| Storage | FTP; SFTP; Micro SD card (max. 1 TB); NAS |
| Browser | IE 9+, Chrome 102+, Firefox 88+ |
| Management Software | SmartPSS Lite; DSS; DMSS |
| Mobile Client | iOS; Android |
| Cyber Security | Configuration encryption, trusted boot, trusted upgrade and certificate support; HTTPS, IP/MAC filtering, 802.1x, syslog, security logs, etc. |
| Certification |
|---|
| Certifications | CE-LVD: EN62368-1; CE-EMC: 2014/30/EU; FCC: 47 CFR Part 15; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14; UL 50E NEMA Type 4X (optional) |
| Port |
|---|
| RS-485 | 1 (baud rate: 1200 – 115200 bps) |
| Audio Input | 1 channel (terminal) |
| Audio Output | 1 channel (terminal) |
| Alarm Input | 3 channel in: wet contact, 5 mA 3 V – 5 V DC |
| Alarm Output | 2 channel out: dry contact, 1000 mA 30 V DC / 500 mA 50 V AC |
| Analog Output | 1 channel (CVBS output: internal 2-pin) |
| Power Output | 12 V DC, max. 165 mA, peak 700 mA |
| Power |
|---|
| Power Supply | 12 V DC / 24 V AC / PoE+ (802.3at) / ePoE |
| Dual Power Backup | When the power adapter and PoE are connected at the same time, the device keeps working if one is disconnected, but will not restart |
| Power Consumption | Basic: 4.1 W (12 V DC); 5.2 W (24 V AC); 5 W (PoE); Max.: 12.9 W / 15.8 W / 15.9 W; Heater: 3 W / 3.8 W / 3.9 W |
| Environment |
|---|
| Operating Temperature | –40 °C to +60 °C |
| Operating Humidity | ≤ 95% |
| Storage Temperature | –40 °C to +60 °C |
| Storage Humidity | 10% – 95% (non-condensing) |
| Ingress Protection | IP67; IK10 |
| Structure |
|---|
| Casing | Metal |
| Dimensions | Φ158 mm × 129.1 mm |
| Net Weight | 1.1 kg |
| Gross Weight | 1.6 kg |
