| Camera |
| Image Sensor |
1/2.7" CMOS |
| Max. Resolution |
2592 (H) × 1944 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.003 lux@F1.0 (Color, 30 IRE); 0.0003 lux@F1.0 (B/W, 30 IRE); 0 lux (illuminator on) |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
30 m (98.43 ft) (IR); 30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
2 (IR LED); 2 (warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Field of View |
2.8 mm: Horizontal: 97° × Vertical: 70° × Diagonal: 128°; 3.6 mm: Horizontal: 78° × Vertical: 58° × Diagonal: 102° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 1.5 m (4.92 ft); 3.6 mm: 2.2 m (7.22 ft) |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
66.0 m (216.54 ft) |
26.4 m (86.61 ft) |
13.2 m (43.31 ft) |
6.6 m (21.65 ft) |
| 3.6 mm |
78.0 m (255.91 ft) |
31.2 m (102.36 ft) |
15.6 m (51.18 ft) |
7.8 m (25.59 ft) |
|
| Professional, intelligent |
| IVS (Perimeter Protection) |
Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
| SMD 3.0 |
Less false alarm, longer detection distance |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2592 × 1944@(1 fps–20 fps) / 2688 × 1520@(1 fps–30 fps); Sub stream: 704 × 576@(1 fps–25 fps) / 704 × 480@(1 fps–30 fps); Third stream: 1920 × 1080@(1 fps–30 fps); *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability |
3 streams |
| Resolution |
5M (2592 × 1944); 4M (2688 × 1520 / 2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); CIF (352 × 288 / 352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps–20480 kbps; H.265: 3 kbps–20480 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE: IE8/9/11; Chrome; Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
iOS; Android |
| Certification |
| Certification |
CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5mA 3V–5 VDC |
| Alarm Output |
1 channel out: 300mA 12 VDC |
| Power |
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 2.4 W (12 VDC); 3.1 W (PoE); Max. (H.265+main stream/IR intensity+warm light on): 7.9 W (12 VDC); 9.7 W (PoE) |
| Environment |
| Operating Conditions |
–40 °C to +60 °C (–40 °F to +140 °F) / Less than 95% RH |
| Storage Conditions |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Metal + plastic |
| Dimensions |
288.4 mm × 94.4 mm × 84.7 mm (11.4" × 3.7" × 3.3") (L × W × H) |
| Net Weight |
1.0 kg (2.20 lb) |
| Gross Weight |
1.23 kg (2.71 lb) |
