| Camera |
| Image Sensor |
1/2.7" CMOS |
| Max. Resolution |
2960 (H) × 1688 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s – 1/100,000 s |
| Min. Illumination |
0.007 lux@F1.6 (Color, 30 IRE); 0.0007 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 30 m (98.43 ft) (IR) |
| Illuminator On/Off Control |
Auto; Manual |
| Illuminator Number |
1 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: H: 111°; V: 58°; D: 132° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 1.1 m (3.61 ft) |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
63.6 m (208.66 ft) |
25.4 m (83.33 ft) |
12.7 m (41.67 ft) |
6.4 m (21.00 ft) |
|
| Intelligence |
| IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream: 2960 × 1668@(1–20 fps) / 2688 × 1520@(1–25/30 fps); Sub stream: 704 × 576@(1–25 fps) / 704 × 480@(1–30 fps) |
| Stream Capability |
2 streams |
| Resolution |
2960 × 1668; 2880 × 1620; 2688 × 1520; 3M (2048 × 1536); 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps – 8192 kbps; H.265: 12 kbps – 8192 kbps |
| Day/Night |
Auto (ICR) / Color / B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour; P2P |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI |
| User/Host |
20 (Total bandwidth: 48 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser |
IE; Chrome; Firefox |
| Management Software |
SmartPSS Lite; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Cyber Security |
| Cyber Security |
Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification |
| Certification |
| Certifications |
CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Power |
| Power Supply |
12 VDC / PoE (802.3af) |
| Power Consumption |
Basic: 2.2 W (12 VDC); 2.9 W (PoE); Max. (H.265+ max. resolution + max. stream + WDR + IR intensity + IVS): 4.1 W (12 VDC); 5.0 W (PoE) |
| Environment |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity |
≤95% |
| Protection |
IP67 |
| Structure |
| Casing Material |
Inner core: Metal; Cover: Plastic |
| Product Dimensions |
100.9 mm × Φ109.9 mm (3.97" × Φ4.33") |
| Net Weight |
0.37 kg (0.82 lb) |
| Gross Weight |
0.56 kg (1.23 lb) |
