Warns with light and sound on alarm and records the event at 8 MP.

A fixed-focal eyeball camera that combines infrared and warm white light. Red and blue lights and a speaker give a deterrent warning at the moment of detection, and dual built-in microphones carry two-way talk.

8 MPResolution

1/2.7" CMOSSensor

2.8 / 3.6 mmFocal length

30 mIR LED distance

IP67Protection grade

12 VDC/PoEPower supply

Key features

120dB

Wide dynamic range

Holds facial detail at backlit spots such as a doorway.

30m

Warm light distance

The warm white LED lights the scene for color video at night.

0.004lux

Color in low light

The F1.0 aperture keeps color recording going in dim scenes.

1/1channel

Alarm input and output

Connects an external detector and drives the relay output on alarm.

10.1W

PoE peak draw

Consumption stays below this figure with light and audio both active.

IN DAILY USE

Warns, not just recordsOn alarm the red and blue lights flash and the speaker sounds an audible warning.

Talks backDual built-in microphones and a speaker carry two-way audio with the person at the door.

Goes quiet on one tapIt disables the alarm output, the email and the light during the configured hours.

ApplicationsIndoor surveillance·Active deterrence·Perimeter protection

Camera

Image Sensor

1/2.7" CMOS

Max. Resolution

3840 (H) × 2160 (V)

ROM

256 MB

RAM

2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s – 1/100,000 s

Min. Illumination

0.004 lux@F1.0 (Color, 30 IRE)
0.0004 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on)

S/N Ratio

> 56 dB

Illumination Distance

Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

1 (IR LED); 1 (Warm light)

Pan/Tilt/Rotation Range

Pan: 0° – 360°; Tilt: 0° – 78°; Rotation: 0° – 360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F1.0

Field of View

2.8 mm: H: 106°; V: 55°; D: 125°
3.6 mm: H: 85°; V: 45°; D: 102°

Iris Type

Fixed

Close Focus Distance

2.8 mm: 1.5 m
3.6 mm: 2.2 m

DORI Distance

Lens	Detect	Observe	Recognize	Identify
2.8 mm	66 m	26.4 m	13.2 m	6.6 m
3.6 mm	78 m	22.2 m	15.6 m	7.8 m

Intelligent

IVS (Perimeter Protection)

Tripwire; intrusion (support the classification and accurate detection of vehicle and human)

SMD

SMD 4.0

AcuPick

Deep-learning-based human and vehicle target matching and search

AI SSA (Scene Self-adaptation)

Adopt deep learning algorithms to adjust the image parameters to suit the conditions

Smart Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

AI Coding

AI H.265; AI H.264

Video Frame Rate

Main stream: 3840 × 2160@1–30 fps
Sub stream: 704 × 576@1–25 fps / 704 × 480@1–30 fps
Third stream: 1920 × 1080@1–30 fps

Stream Capability

3 streams

Resolution

8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728 / 2592 × 1944); 4M (2688 × 1520 / 2560 × 1440); 3M (2048 × 1536 / 2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps – 8192 kbps
H.265: 12 kbps – 8192 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

Scene Self-adaptation (SSA)

Yes

White Balance

Auto; natural; street lamp; outdoor; manual; regional custom

Gain Control

Auto; manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas)

Region of Interest (RoI)

Yes (4 areas)

Smart Illumination

Yes

Defog

Yes

Image Rotation

0°/90°/180°/270° (support 90°/270° with 2688 × 1520 resolution and lower)

Mirror

Yes

Privacy Masking

8 areas

Audio

Built-in MIC

Yes, built-in dual MIC

Built-in Speaker

Yes

Audio Compression

PCM; G.711a; G.711Mu; G.726; G.723

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Interoperability

ONVIF (Profile S; Profile G; Profile T); CGI

User/Host

20 (Total bandwidth: 72 M)

Storage

FTP; SFTP; Micro SD card (support max. 256 G); NAS

Browser

IE: IE8/9/11; Chrome; Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

iOS; Android

Certification

CE-LVD: EN 62368-1
CE-EMC: 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL 62368-1 & CAN/CSA C22.2 No. 62368-1-14

Port

Audio Input

1 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

1 channel in: 5 mA 3 – 5 VDC

Alarm Output

1 channel out: 300 mA 12 VDC

Power

Power Supply

12 VDC/PoE (802.3af)

Power Consumption

Basic: 4.5 W (12 VDC); 5.8 W (PoE)
Max.: 8.6 W (12 VDC); 10.1 W (PoE)

Environment

Operating Conditions

−40 °C to +60 °C (−40 °F to +140 °F); less than 95% RH

Storage Conditions

−40 °C to +60 °C (−40 °F to +140 °F)

Protection Grade

IP67

Structure

Casing

Metal

Dimensions

Φ122.0 mm × 110.9 mm (Φ4.80" × 4.37")

Net Weight

0.75 kg (1.65 lb)

Gross Weight

0.92 kg (2.03 lb)
