Stock Code: BT43-179
| General Information | |
|---|---|
| Part Number | BT43-179 |
| Brand | upTech |
| Product Type | BT43 (Type 43) coaxial connector |
| Termination Type | Crimp |
| Compatible Cable | RG-179 |
| Impedance | 75 Ω |
| Country of Origin | Taiwan (Made in Taiwan) |
| Mechanical Specifications | |
| Overall Length | 27.8 mm (reference) |
| Max. Body Diameter | ø10.1 mm |
| Contact Length | 10.6 mm |
| Materials and Plating | |
| 1. Shell | Brass / Nickel plated |
| 2. Washer | Steel / Nickel plated |
| 3. Spring | Steel / Nickel plated |
| 4. Body | Brass / Nickel plated |
| 5. Insulation | Teflon / Natural (unplated) |
| 6. Body | Brass / Nickel plated |
| 7. Contact | Beryllium Copper (Be.Cu) / Gold plated |
| 8. Ring | Brass / Nickel plated |
