Stock Code: ARM9A4-W2
| Input & Output Capacity | |
|---|---|
| Wired Alarm Inputs | 16 Local Channels (Channels 1–6 Support Pulse Detection; Channels 1–16 Support 0EOL/EOL/2EOL/3EOL) |
| Alarm Outputs | 4 Local Relay Channels (Max. 30 VDC, 3A) |
| Auxiliary Power Output | 2 Built-in Auxiliary Outputs (14.5 V, Total 2 A) |
| Wireless & Functional Specifications | |
| Wireless Communication | 433 MHz Two-way / Up to 1,200 m (Open Space) |
| Security Mechanism | AES128 Encryption & Frequency Hopping (FHSS) |
| Management | Cloud Remote Update / Tamper Protection / Low Battery Detection |
| Power & Physical Parameters | |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Backup Battery | Supports 12 V 7 Ah Battery (Up to 30 Hours Static Standby) |
| Operating Temperature | –10°C ~ +50°C |
| Operating Humidity | 10% – 90% |
| Dimensions / Weight / Material | 304 mm × 235 mm × 90.8 mm / 1.22 kg / PC + ABS (IP30) |
