Tells outdoor motion apart despite rain and light.
A triple-tech PIR detector built for outdoor use, rated IP55 and mounted on a wall at 2.2 m. It scans a 12 m range across a 110° angle and works on garden and perimeter protection lines.
Outdoor protectionThe IP55 rated, fully sealed housing keeps water and pests out.
Triple technologyX-Band patch antenna microwave, Doppler effect and energy analysis decide together with the PIR channel.
White light immunityA special optical filter lens blocks false alarms under white light up to 10000 Lux.
Pet immunityPets up to 20 kg do not trigger the alarm.
Field adjustmentMicrowave detection range adjusts on site, with selectable pulse count, LED state and N.C./N.O. output.
Wide temperature rangeOperates from -25°C to +55°C and draws 30 mA.
