•Support 8xGigabit combo ports and 4x1000Base-X SFP ports
•Support Jumbo frame up to 9K Bytes
•Supports O-Ring (recovery time < 30ms over 250 units of connection), MSTP/RSTP/STP (IEEE 802.1s/w/D) for Ethernet Redundancy
•Supports IP-based bandwidth management
•Supports application-based QoS management
•Supports Device Binding security function
•Supports DOS/DDOS auto prevention
•Supports DDM (Digital Diagnostic Monitoring) function (P1 ~ P8)
•IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
•Supports SNMP v1/v2c/v3, RMON and 802.1Q VLAN Network Management
•Support ACL, 802.1x User Authentication for security
•Windows utility (Open-Vision) support centralized management and configurable by Web-based interface, Telnet and Console (CLI)
•Multiple notification for warning of unexpected event
•Support LLDP Protocol
•Rigid IP-30 housing design
•DIN-Rail and wall mounting enabled
