Stock Code: RG-AP740-I
| Technical Specifications | |
|---|---|
| RF | Tri-band, dual-radio |
| Transmission Protocol | Three radio frequency cards support concurrent 802.11a/b/g/n, 802.11ac Wave 1 and 802.11ac Wave 2 Operating modes of 2.4G+5G+2.4G and 2.4G+5G+5G are supported |
| Operating Bands | 802.11b/g/n: 2.4GHz to 2.483GHz 802.11a/n/ac: 5.15GHz to 5.35GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.85GHz (Country-Specific) |
| Antenna | Built-in X-Sense Smart Antenna array |
| Spatial Streams | 9 streams: 4x4 SU-MIMO, 4x4 MU-MIMO, 1x1 SISO |
| Working Bandwidth | HT160(80+80), HT80, HT40, HT20 |
| Max Throughput | 802.11b/g/n: up to 800Mbps 802.11a/n/ac: up to 1,734Mbps and 433Mbps Up to 2,967Mbps per AP |
| Modulation | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
| Receive Sensitivity | 11a: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps) 11b/g: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps) 11n: -86dBm@MCS0, -68dBm@MCS7, -86dBm@MCS8, -68dBm@MCS15 11ac HT20: -83dBm(MCS0), -64dBm(MCS8) 11ac HT40: -80dBm(MCS0), -58dBm(MCS9) 11ac HT80: -77dBm(MCS0), -52dBm(MCS9) 11ac HT160(80+80): -74dBm(MCS0), -50dBm(MCS9) |
| Transmit Power | ≤100mw (20dBm) |
| Transmit Power Adjustment | 1dBm |
| Dimensions | 230mm x 230mm x 47mm (9.06in. x 9.06in. x 1.85in.) (W x D x H) |
| Weight | 1.3kg (2.87lbs) |
| Service Ports | Two 10/100/1000BASE-T Ethernet uplink ports (PoE-capable); one USB port |
| Management Ports | One Console port |
| Reset Button | Support |
| Anti-theft Locks | Support |
| LED | 1 LED (red, green, blue and orange light for solid mode, flashing mode or breathing flashing mode, and the indicator can be switched off to silent mode) |
| Power Supply | Adapter: DC 48V (optional) PoE: IEEE 802.3af/802.3at-compliant Dual PoE for power backup of the 802.3at or dual 802.3af power supplies Note: When power is supplied by dual 802.3at, USB is supported. When power is supplied by single 802.3at, radio1 2.4G@1X4 and radio2 5G@3X4 modes are supported |
| Power Consumption | < 25.4W |
| Bluetooth | Bluetooth 4.0 (BLE) and Apple iBeacon protocol are supported Bluetooth applications, such as Shake and locating, can be extended. |
| Temperature | Operating: -10°C to 50°C (14°F to 122°F) Storage: -40°C to 70°C (-40°F to 158°F) |
| Humidity | Operating: 5% to 95% RH (non-condensing) Storage: 5% to 95% RH (non-condensing) |
| Installation | Ceiling/wall mount |
| IP Rating | IP41 |
| Safety Standards | GB4943 EN/IEC 60950-1 |
| EMC Standards | GB9254 EN301 489 |
| Radio | China Radio Transmission Equipment Type Approval Certificate EN300 328 EN301 893 |
