Stock Code: ARA13-W2
| Function | |
|---|---|
| Indicator Light | 1 × green pairing indicator 12 × alarm LED groups |
| Button | 1 × power switch |
| Buzzer | 1 × buzzer |
| Remote Update | Cloud update |
| Low Battery Detection | Yes |
| Battery Level Display | Yes |
| Tamper | Yes |
| Signal Strength | Signal strength detection |
| Wireless | |
| Carrier Frequency | 433.1 MHz–434.6 MHz |
| Transmitter Power (EIRP) | Limit 10 mW |
| Communication Distance | Up to 1,200 m (3,937.01 ft) in an open space |
| Communication Mechanism | Two-way |
| Frequency Hopping | Yes |
| Encryption Mode | AES128 |
| General | |
| Power Supply Mode | 4 × CR123A battery / 9–15 VDC |
| Battery Model | CR123A |
| Battery Life | 4 CR123A batteries can be used for 3.4 years (if triggered fortnightly and the alarm sounds for 120 s each time with a battery efficiency of 80%) |
| Operating Temperature | –25 °C to +60 °C (–13 °F to +140 °F) |
| Operating Humidity | 10%–90% (RH) |
| Product Dimensions | 200 mm × 200 mm × 52.5 mm (7.87" × 7.87" × 2.07") (L × W × H) |
| Packaging Dimensions | 255 mm × 239 mm × 64 mm (10.04" × 9.41" × 2.52") (L × W × H) |
| Net Weight | 610 g (1.34 lb) |
| Gross Weight | 920 g (2.03 lb) |
| Installation | Wall mount |
| Casing | PC + ABS |
| Protection | IP65 |
| Certifications | CE; FCC |
| Technical | |
| Scenario | Outdoor |
| Operating Current | Max 1.4 A, 92 µA (standby), battery 3 V Max 1 A, 7.3 mA (standby), 12 VDC |
| Sound and Light Alarm | Light alarm and multiple alarm sounds, including fire, medical, intrusion, panic, and more. |
| Sound Pressure | Maximum: 110 dB(A) at 1 meter Minimum: 95.2 dB(A) at 1 meter |
