| General Information |
|---|
| Product Size / Packing Size (L*W*H) | 440mm*190mm*44.5mm |
| Warranty | 2 years (Accessories not included) |
| Network Specifications |
|---|
| VLAN Configuration | Port-based VLAN supported |
| Speed Limitation | Bandwidth management based on port input and output |
| Cable Sequence | Auto-MDIX; auto detection on straight-through and cross-over cable |
| Diagnostics |
|---|
| LED Indicator | PWR: Power LED |
| Power Supply |
|---|
| Power | Built-in power supply AC 100~240V 50/60Hz |
| Electrical Data |
|---|
| CPU | 500M Hz |
| Buffer | Fully integrated 4.1M packet buffer |
| Flash | 16M |
| RAM | 128M |
| Lightning Protection Level | 4KV 8/20us; |
| Dimensions and Weight |
|---|
| N.W/G.W (kg) | 2.5kg/3kg |
| Environmental Conditions |
|---|
| Operating Temperature/Humidity | -20 - +55°C; 5% - 90% RH, non-condensing |
| Storage Temperature/Humidity | -40 - +75°C; 5% - 95% RH, non-condensing |
| Certifications |
|---|
| Certificate | CE mark, commercial; CE/LVD EN60950; |
| Safety | User port+IP address+MAC address supported |
| Other Specifications |
|---|
| Network Port | 16*10/100/1000Base-TX PoE |
| PoE Port | Ports 1-16 support IEEE802.3 af/at |
| Console Port | 1*console port |
| Reset Button | 1 |
| DDR | 1G DDR3 1333MHz |
| Bandwidth | 56 Gbps |
| Packet Forwarding | 40.32Mpps |
| MAC Address | 8K |
| Network Standard | IEEE 802.3 |
| Port Specification | 10/100/1000BaseT (X) Auto |
| Transmission Mode | Store-and-Forward (full wirespeed) |
| Transmission Distance | 10BASE-T: Cat3,4,5 UTP (≤250 meter) |
| Total Watt | ≤250W |
| Installation | 1U, Rack type, 19" (optional rack mounting parts) |
| SNMP | IP30 |
| Network Protocol | IEEE 802.3x |
| MAC | Supports 8K MAC addresses, auto aging and learning |
| Spanning Tree | STP (Spanning Tree Protocol) |
| Port Aggregation | Supports 8 aggregation groups, each group supports up to 8 ports; |
| Port Mirroring | Supports many-to-one port mirroring |
| Loop Guard | Supports loop protection with automatic recovery |
| Port Isolation | Supports downlink ports isolated from each other while still communicating with the uplink port |
| Flow Control | Back pressure based in half duplex mode; |
| Multicast Control | IGMPv1/2/3 and MLDv1/2 Snooping |
| DHCP | DHCP Snooping |
| Storm Suppression | • Supports unknown unicast, multicast, unknown multicast, broadcast
• type storm suppression |
| QoS | 802.1p port queue priority algorithm |
| Negotiation Mode | Ports support auto-negotiation (self-negotiating transmission rate and duplex mode) |
| System Maintenance | Upgrade package upload |
| PoE Function | Port Switch |
| Network Management | WEB interface management |
