Stock Code: MLCDF7-T
| Screen | |
|---|---|
| Resolution | 1024P × 600P |
| Touch Screen | Support |
| Backlight | LED |
| Brightness | Self-adaptive / Manually set |
| Button | ① Screen on/off ② MENU (menu of screen, including brightness setting and version info) ③ Volume up ④ Volume down ⑤ Mirror setting ⑥ F1 (display main menu of MXVR/MNVR) ⑦ F2 (Back) |
| Mirror | Support |
| Port | |
| Video Input | 1 channel video input (VGA) |
| Audio Input | 1 channel, VGA |
| Audio Output | 1 channel, speaker |
| Power Supply | |
| Protection Circuit | Support, +/- reverse protection |
| Working Voltage | 12V DC |
| Power Consumption | ≤6W |
| Structure | |
| Installation Method | Bracket mounting |
| Dimension | 181.4 mm × 121.6 mm × 27.7 mm |
| Cable Length | 1 m (5 m extension cable is included) |
| Net Weight | 450 g |
| Environment | |
| Operating Temperature | –30°C to +70°C (–22°F to +158°F) |
| Operating Humidity | 0%–95% RH (non-condensing) |
