Stock Code: KT101
| General | |
|---|---|
| Product Type | Professional Cable Tester |
| Test Functions | |
| Open / Short Circuit Test | Yes |
| Connected Cable Indication | Yes |
| No Connection / No Termination Indication | Yes |
| Incorrect Wiring / Split Pair Indication | Yes |
| BNC Termination Indication | 25 / 50 |
| Ethernet 10BASE-2 Termination Value Detection | Yes |
| Remote Point Testing | Via detachable remote unit |
| Max. Cable Length | 300 m (RJ-45 / RJ-11 / BNC) |
| Indication and Operation | |
| Display | Clear and easy-to-read LED display |
| Test Mode | Single-button auto test (Auto Test), instant results |
| Battery Status Indicator | Yes |
| Power | |
| Power Supply | 9 V alkaline battery |
| Physical Specifications | |
| Dimensions | 143 × 85 × 25 mm (5 5/8" × 3 3/8" × 1") |
| Weight | 175 g (0.38 lbs) |
| Carrying Case | Yes |
| Compliance | |
| Emission Safety | FCC Class B; CE Class B |
