Protects a single-pole 10 A circuit against overcurrent and short circuit

A single-pole miniature circuit breaker one module wide. It carries a nominal current of 10 A, trips on the C curve and protects the circuit against overcurrent and short circuit. It sits in the distribution boards of residential, commercial and industrial installations.

10 ANominal Current

1PNumber of Poles

6 kABreaking Capacity

1MNumber of Modules

500 VInsulation Voltage

Key features

Protection functionIt trips the circuit on overcurrent and disconnects the load on a short circuit.

Rated valuesThe single-pole body carries a nominal current of 10 A and trips on the C curve.

Breaking capacityIt clears 6000 A at 230 V to IEC/EN 60898 and 6 kA to IEC/EN 60947-2.

Terminals and cable cross-sectionTerminals accept solid and stranded cable up to 25 mm² with a rated tightening torque of 2 Nm.

Insulation and withstandIt carries a 500 V insulation voltage and a 4 kV rated impulse withstand voltage, and runs at a 50/60 Hz supply frequency.

Endurance and temperatureIt runs through 4000 electrical and 10000 mechanical operations, works from -25 to +40 °C and is stored from -25 to +80 °C.

A qualified electrician carries out the panel installation.

Technical Specifications

Standard

IEC/EN 60898, IEC/EN 60947-2

Rated frequency (Hz)

50/60 Hz

Breaking capacity EN 60898 230V (Icn)

6000 A

Breaking capacity EN 60898 (Ics)

1 x Icn

Breaking capacity IEC/EN 60947-2 230V (Icu)

6 kA

Breaking capacity IEC/EN 60947-2 (Ics)

100% Icu

Insulation voltage (Ui)

500 V

Rated impulse withstand voltage (Uimp)

4 kV

Electrical endurance

4000

Mechanical endurance

10000

Solid cable cross-section

max 25 mm²

Flexible cable cross-section

max 25 mm²

Rated tightening torque

2 Nm

Operating temperature

-25 +40 °C

Storage temperature

-25 +80 °C

Electrocod

1411
