Protects a three-pole 25 A circuit against overcurrent and short circuit
A three-pole miniature circuit breaker three modules wide. It carries a nominal current of 25 A, trips on the C curve and protects all three phases against overcurrent and short circuit on a 400 V supply. It sits in the distribution boards of residential, commercial and industrial installations.
25 ANominal Current
3PNumber of Poles
6 kABreaking Capacity
3MNumber of Modules
400 VRated Voltage
Key features
Protection functionIt opens all three poles together on overcurrent and disconnects the load on a short circuit.
Rated valuesThe three-pole body carries a nominal current of 25 A and trips on the C curve.
Breaking capacityIt clears a 6 kA short-circuit current.
Supply compatibilityIt works on a 400 V rated voltage.
Operating TemperatureIt works from -25 to +40 °C.
Panel footprintIt takes up 3 modules of width inside the board.
A qualified electrician carries out the panel installation.
