Makes Type B residual current protection visible with a green status LED.
This four-pole residual current circuit breaker protects three-phase circuits up to 25 A and opens its contacts at a 30 mA leakage. Its Type B design maintains service continuity under harmonic distortion and meets the IEC/EN 62423 standard.
Earth leakage protectionMonitors earth leakage and opens the circuit at the 30 mA threshold.
Load currentCarries up to 25 A across four poles.
Sensitivity typeA Type B device holds service through harmonic distortion with short-time delayed tripping.
Space in the boardA 4 module wide modular housing fits the distribution board.
Supply compatibilityOperates at a 50/60 Hz supply frequency.
Insulation and impulse withstandWithstands a 500 V insulation voltage, a 4 kV rated impulse voltage and a 3000 A surge current with an 8/20 µs waveform.
![RCCB 4P 63A A[IR] 300mA 4M Residual Current Circuit Breaker](https://noktanet.s3.eu-central-1.amazonaws.com/uploads/images/products/66cda9ff6de13_GWD4224.webp)
