Combines two SDI sources into a single output and switches between them instantly.

An SDI switch built with an equalizer IC on its inputs and a drive IC on its output. It carries SD-SDI, HD-SDI and 3G-SDI signals arriving over long coaxial cable without degradation. It changes the source shown on the SDI monitor instantly.

2×1Input to output layout

3G-SDIHighest supported standard

1080pHighest supported format

12 bitColor depth

Key features

Signal supportHandles SD-SDI, HD-SDI and 3G-SDI signals on the same slot.

Resolution rangePasses SD 525i and 625i along with HD 720p, 1080i and 1080p formats.

Color spaceRecognizes RGB and YCbCr 4:4:4, 4:2:2 and 4:2:0 sampling.

Color depthCarries 8 bit, 10 bit and 12 bit deep color.

Cable reachThe input and output stages drive long coaxial cable.

Standards complianceComplies with HDcctv 1.0, ST 292, ST 424 and ST 259.

General Specifications

Product Type

2×1 SDI Switch

Input / Output

2 inputs / 1 output (2×1)

Supported Signals

SD-SDI, HD-SDI, 3G-SDI

Switching

Arbitrary switching between the two input signals

Source Switching

The signal source displayed on the SDI monitor can be changed instantaneously
