Converts an SMA male line to an RP-SMA female interface.
A converter connector that links a reverse-polarity SMA interface to a standard SMA line. The subminiature body fits high-frequency connection points where space is tight. It forms an intermediate link on radio communication, broadcasting and telecommunication lines.
ConnectionOne end carries an SMA male interface and the other an RP-SMA female interface, so it bridges the two ends directly.
Frequency bandIt operates across 0 - 18 GHz and carries high-frequency lines.
Signal lossInsertion loss stays at 0.06 dB at 6 GHz, and VSWR remains within 1.3 on the straight version and 1.5 on the right-angle version.
Body and platingThe body and the contact pin carry gold plating, which keeps signal loss to a minimum.
Intended useIt forms an intermediate link on RF lines that call for high frequency and miniaturization.
