Carries VGA video together with audio to HDTV screens.
Connects computers with a VGA output to HDTVs and monitors with an HDMI input, while the USB interface both carries the audio and powers the converter. No separate power adapter is needed.
USB 2.0 + VGAInput interfaces
HDMIOutput interface
1920x1080pMax. resolution
1.65 Gbps / 165 MHzVideo bandwidth
50/60HzVertical frequency range
0°C to +40°COperating temperature
Audio and video on one linkCombines the VGA picture with audio arriving over USB and sends it to the HDTV through a single HDMI connection.
Full HD resolutionRuns up to 1920x1080p and supports the standard VGA resolutions.
Color depthCarries 8-bit color depth per channel and 24-bit across all channels.
BandwidthHandles 1.65 Gbps per channel and 6.75 Gbps across all channels on the HDMI input.
Operating system supportWorks with Windows Server 2008, XP, Vista, 7, 8 (32/64-bit) and MAC OS X 10.8.
USB poweredDraws its operating power from the USB port and needs no external adapter.
