Stock Code: ARD1731-W2
| Video & Audio | |
|---|---|
| Field of View | 88° (H); 68° (V) |
| Image Type | JPEG |
| Resolution | 1600 × 1200; 1280 × 960; 640 × 480; 320 × 240 |
| Frame Rate | 2 |
| Illumination Mode | Infrared Light |
| Illumination Range | 12 m (39.37 ft) |
| Day/Night Switch | Color / Black & White |
| Function | |
| Indicator Light | 1 × green alarm indicator |
| Button | 1 × power switch |
| Remote Update | Cloud update |
| Low Battery Detection | Yes |
| Tamper | Tamper alarm |
| Technical | |
| Detection Mode | PIR |
| Sensitivity | 3 levels adjustable |
| Detection Range | 12 m (39.37 ft) (86°) with installation height of 2.2 m (7.22 ft) |
| Detection Speed | 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s) |
| Pet Immunity Level | ≤18 kg (39.68 lb) |
| White Light Resistance Level | 2000 lux |
| Two-way Digital Temperature Compensation | Yes |
| Scenario | Indoor |
| Operating Current | 2 A (Max), 65 µA (Standby) (Battery 3V) |
| Wireless | |
| Carrier Frequency |
RF: 433.1 MHz–434.6 MHz RF-HD: 2.4 GHz (Upload images at high speed) |
| Transmitter Power (EIRP) | Max. 10 mW |
| Communication Mechanism | Two-way |
| Communication Distance | RF: Up to 1,200 m (3,937.01 ft) in an open space |
| RF-HD: Upload images at high speed: Up to 300 m (984.25 ft) | |
| RF-HD: Upload images at normal speed: Up to 1,200 m (3,937.01 ft) | |
| Encryption Mode | AES128 |
| Frequency Hopping | Yes |
| General | |
| Power Supply | CR123A*3 |
| Battery Life | 4 years (if triggered twice a week with a battery efficiency of 70%) |
| Power Consumption | 6 W (Max), 0.2 mW (Standby) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 10%–90% (RH) |
| Product Dimensions | 71.0 mm × 53.2 mm × 127.6 mm (2.80" × 2.09" × 5.02") |
| Net Weight | 202 g (0.45 lb) |
| Gross Weight | 333 g (0.73 lb) |
| Installation | Wall mount |
| Casing | PC + ABS |
| Certifications | CE; FCC |
| Anti-corrosion Level | Basic Protection |
| Storage Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Humidity | 10%–90% (RH) |
| Packaging Dimensions | 121.0 mm × 65.0 mm × 170.0 mm (4.76" × 2.56" × 6.69") (L × W × H) |
| Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
| Wi-Fi Frequency Range | 2400-2483.5 MHz |
| Wi-Fi Power Transmission | CE EIRP: ≤20 dBm@2400-2483.5MHz FCC output power: ≤30 dBm@2400-2483.5MHz |
