Артикул: SD49425XB-HNR
| Camera | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Image Sensor | 1/2.8" STARVIS™ CMOS | ||||||||
| Pixel | 4MP | ||||||||
| Max. Resolution | 2560 (H) × 1440 (V) | ||||||||
| ROM | 4GB | ||||||||
| RAM | 1GB | ||||||||
| Electronic Shutter Speed | 1/1 s–1/30,000 s | ||||||||
| Scanning System | Progressive | ||||||||
| Min. Illumination | Color: 0.005Lux@F1.6 B/W: 0.0005Lux@F1.6 0Lux@F1.6 (IR light on) | ||||||||
| Illumination Distance | 100 m (328.08 ft) | ||||||||
| Illuminator On/Off Control | Zoom Prio/Manual/SmartIR | ||||||||
| Illuminator Number | 4 | ||||||||
| Lens | |||||||||
| Focal Length | 4.8 mm–120 mm | ||||||||
| Max. Aperture | F1.6–F4.0 | ||||||||
| Field of View | H: 60.0°–2.5°; V: 30.8°–2.2°; D: 66.7°–2.9° | ||||||||
| Optical Zoom | 25x | ||||||||
| Focus Control | Auto/Semi-Auto/Manual | ||||||||
| Close Focus Distance | 0.1 m–1.5 m (0.33 ft–4.92 ft) | ||||||||
| Iris Control | Auto/Manual | ||||||||
| DORI Distance |
| ||||||||
| PTZ | |||||||||
| Pan/Tilt Range | Pan: 0°–360° (endless) Tilt: -15°–90° (auto flip 180°) | ||||||||
| Manual Control Speed | Pan: 0.1°–200°/s Tilt: 0.1°–120°/s | ||||||||
| Preset Speed | Pan: 240°/s Tilt: 200°/s | ||||||||
| Presets | 300 | ||||||||
| Tour | 8 (up to 32 presets per tour) | ||||||||
| Pattern | 5 | ||||||||
| Scan | 5 | ||||||||
| Speed Adjustment | Support | ||||||||
| Power-off Memory | Support | ||||||||
| Idle Motion | Preset/Tour/Pattern/Scanning | ||||||||
| Protocol | DH-SD Pelco-P/D (auto recognition) | ||||||||
| General Intelligence | |||||||||
| Event Trigger | Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly | ||||||||
| IVS | Object Abandoned/Missing | ||||||||
| Artificial Intelligence | |||||||||
| Perimeter Protection | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. | ||||||||
| SMD PLUS | Support | ||||||||
| Face Detection | Support | ||||||||
| Smart Capture | Support human, motor vehicle and non-motor vehicle image capture. | ||||||||
| Video | |||||||||
| Compression | H.265+/H.265/H.264+/H.264/MJPEG (sub stream) | ||||||||
| Streaming Capability | 3 streams | ||||||||
| Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) | ||||||||
| Frame Rate | Main stream: 4MP/3MP/1080P/1.3MP/720P (1–25fps) Sub stream 1: D1/CIF (1–25fps) Sub stream 2: 1080P/1.3M/720P (1–25fps) | ||||||||
| Bit Rate Control | Variable/Constant | ||||||||
| Bit Rate | H.265/H.264: 3 kbps–20480 kbps | ||||||||
| Day/Night | Auto (ICR)/Color/B/W | ||||||||
| BLC | Support | ||||||||
| WDR | 120 dB | ||||||||
| HLC | Support | ||||||||
| White Balance | Auto/Indoor/Outdoor/Track/Manual/Sodium lamp/Natural light/Street lamp | ||||||||
| Gain Control | Auto/Manual | ||||||||
| Noise Reduction | Ultra DNR (2D/3D) | ||||||||
| Motion Detection | Support | ||||||||
| Region of Interest (ROI) | Support | ||||||||
| Electronic Image Stabilization | Support | ||||||||
| Electronic Defog | Support | ||||||||
| Digital Zoom | 16x | ||||||||
| Flip | 180° | ||||||||
| Privacy Masking | Up to 24 areas, and up to 8 areas in the same view | ||||||||
| Audio | |||||||||
| Compression | G.711a; G.711Mu; AAC; G.722.1; G.726; MPEG2-Layer2; G.729 | ||||||||
| Network | |||||||||
| Ethernet | RJ-45 (10/100Base-T) | ||||||||
| Protocol | IPv4; IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMPv1/v2c/v3(MIB-2); ARP; RTCP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x | ||||||||
| Interoperability | ONVIF Profile S&G&T; CGI | ||||||||
| Streaming Method | Unicast/Multicast | ||||||||
| User/Host | 20 | ||||||||
| Storage | NAS; Local PC; Micro SD card (256G) | ||||||||
| Browser | IE7 and newer versions Chrome 45 and earlier versions Firefox 52 and earlier versions Safari (no version restrictions) | ||||||||
| Management Software | Smart PSS; DSS; DMSS | ||||||||
| Mobile Phone | iOS/Android | ||||||||
| Certification | |||||||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL62368-1+CAN/CSA C22.2, No. 62368-1 | ||||||||
| Port | |||||||||
| Audio Input | 1 | ||||||||
| Audio Output | 1 | ||||||||
| Alarm I/O | 2/1 | ||||||||
| Power | |||||||||
| Power Supply | DC 12V/3A PoE+ (802.3at) | ||||||||
| Power Consumption | 13W 21W (IR on) | ||||||||
| Environment | |||||||||
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) | ||||||||
| Operating Humidity | ≤95% | ||||||||
| Protection | IP66; TVS 6000V lightning proof; Surge protection | ||||||||
| Structure | |||||||||
| Dimensions | Φ160 mm × 295 mm (6.30" × 11.61") | ||||||||
| Net Weight | 3 kg (6.61 lb) | ||||||||
| Gross Weight | 4.8 kg (10.58 lb) | ||||||||
