Calls for help at one touch and opens a video and audio link

An emergency call terminal that surface-mounts on a wall. One button reaches the master station, the 4 MP camera sends video, and two-way audio keeps the conversation going.

4 MPCamera

H.264 · H.265Video compression

64 GBStorage

PoE · 12 VDCPower input

IP65 · IK10Protection grade

190 × 120 × 42 mmDimensions

Key specifications

Camera and field of viewThe 4 MP low-illumination CMOS camera covers 104° horizontally, 57° vertically and 113° diagonally. A Starlight image sensor holds detail in the dark and auto IR illumination (ICR) steps in.

VideoUses H.264 and H.265 compression; the main stream runs at 1080p and climbs to 2512 × 1408. Video recording, snapshot capture and pre-record time all stay configurable.

AudioA built-in dual microphone and speaker carry the conversation, with a 3.5 mm external input and output. Echo suppression and digital noise reduction cut the noise, and the unit sends audio and group broadcasts.

Ports and alarmsCarries 2 × alarm inputs, 2 × alarm outputs, 2 × RJ-45 (10/100M) and 1 × RS-485 port. A tamper alarm reports any attack on the casing.

Power inputRuns on standard PoE, takes a 12 VDC 3 A input and delivers a 12 V/1 A output.

Housing and mountingThe silver aluminum alloy body carries IP65 and IK10 protection and sits on the wall with a surface mount.

System & Video Features

Main Processor / OS

Embedded Processor / Embedded Linux OS

Camera Resolution

4MP CMOS High-Definition, Low Illumination

Field of View / Night Vision

H: 104°; V: 57°; D: 113° / Auto IR (ICR)

Video Compression

H.264; H.265 / Main Stream: 1080p (up to 2512 × 1408)

Audio & Functionality

Audio Input / Output

Built-in Dual Mic & Speaker; External 3.5 mm Input/Output

Audio Enhancement / Mode

Echo Suppression and Digital Noise Reduction / Two-way Audio Intercom

Communication / Storage

Full Digital; Micro SD Card (Max. 64 GB) & Auto Snapshot

Connectivity & Physical Parameters

Ports & Alarms

2× Alarm In, 2× Alarm Out, 2× RJ-45 (10/100M), 1× RS-485, Tamper Alarm

Power Supply

12 VDC, 3A / Standard PoE

Protection / Material

IP65, IK10; Aluminum Alloy (Silver)

Dimensions / Installation

190.0 mm × 120.0 mm × 42.0 mm / Surface Mount
