Builds a short in-rack link with an economical PVC jacket.
A CAT5e patch cable with U/UTP construction, 24 AWG conductors and a PVC jacket. With 7/0.20 mm stranded copper conductors and a 5.5 mm outer diameter, it builds 1 m links inside the rack.
CAT5eCable Type
U/UTPShielding
24 AWGCable Thickness
PVCOuter Jacket
1 mLength
Key features
Ethernet supportCarries 1000 Base-TX Gigabit and 10/100Base-TX Fast Ethernet links.
Protocol compatibilitySupports IEEE 802.3 100 VG-AnyLAN and IEEE 802.12 155/622 Mbps ATM.
Service supportRuns 100 MHz broadband video, voice, T1 and ISDN traffic over the same line.
Standards complianceMeets ANSI/TIA 568-C2, ISO/IEC 11801 Class D+ and CENELEC EN 50173-1.
Cable standardsComplies with IEC 61156-6 and CENELEC EN 50288-3-2.
Fire behaviorThe PVC outer jacket passes the IEC 60332-1-2 flame retardancy test.
ORing Networking structured cabling products carry a lifetime warranty.
