Gathers audio and lighting lines into one panel plug
A male multipin connector that sits on the panel surface. It carries gold plated crimp pin contacts in a die cast aluminum shell and mates with the female connector on the cable side.
150multipin count
Maleplug type
Panel typeproduct type
IP67protection grade
Goldcontact plating
Key features
7.5A
Current capacity per contact
Each contact carries the continuous current of audio and lighting lines.
2000cycles
Long mating life
The pair keeps its life in installations that are plugged and unplugged often.
IP67
Sealed against dust and water when mated
The mated pair stays tight against outdoor conditions.
18AWG
Crimp termination
Crimp pin contacts hold the conductor without solder.
-55…+125°C
Wide operating temperature range
The same shell works in low and high temperature environments.
Structure that eases everyday useAudio and lighting installationsIt gathers a large number of audio and lighting lines in one shell.
Fixed panel mountingIt sits in cabinet and rack panels and meets the female connector on the cable side.
Metal shellThe black coated die cast aluminum shell carries the pin block against impact.
Usage areasAudio systems·Lighting installations
The product complies with EU RoHS 2 Directive 2011/65/EU.
