    Noyafa

    2-in-1 Laser Taper measurer

    Stock Code: NF-2260L

    Combines a tape measure and a laser in one body
    A handheld distance meter that measures with a tape and with a laser. It reads from 0.05~60 m with ±2 mm accuracy and calculates distance, area and volume.
    0.05~60 mMeasurement range
    ±2 mmMeasurement accuracy
    630-670 nmLaser wavelength
    1 mWLaser output power
    0°C~40°COperating Temperature
    Key features
    Two measuring methodsUses the tape at close range and the laser over longer distances.
    Distance, area and volumeSwitches between single and continuous readings and calculates area and volume.
    Voice broadcastReads the result aloud and gives a hint tone on each key press.
    Units and benchmarkSwitches among m, ft, in and ft+in and changes the reference point.
    Lithium batteryTurns the laser off after 30 s and the unit after 2 min, running on a lithium battery.
    Screen and keysDrives the backlit FSTN screen with the MEAS, FUNC and CLEAR buttons.
    Specifications
    Range 0.05~60m
    Wavelength 630-670nm
    Output <1mW
    Accuracy ±2mm
    Test time 0.1~3s
    LCD screen FSTN with backlight
    Buttons MEAS, FUNC, CLEAR
    Units m/ft/in/ft+in
    Distance/Area/Volume measurement ✓
    Voice broadcast ✓
    Unit switch ✓
    Benchmark switch ✓
    Hint tone ✓
    Laser auto-off 30s
    Auto-off time 2mins
    Power supply Lithium battery
    Working temperature 0°C~40°C
    Storage temperature -10°C~60°C
    Protection level IP54
    Applied range
    Used for interior design and decoration technology field.
    Construction supervision & on-site detection function.
    Real estate, fire control and assessment of industry planning.
    Public facilities use.
