| Camera |
| Image Sensor |
1/2.8" CMOS |
| Max. Resolution |
1920 (H) × 1080 (V) |
| ROM |
128 MB |
| RAM |
128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s – 1/100,000 s |
| Min. Illumination |
0.0017 lux@F1.0 |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 30 m (98.43 ft) (Warm light) |
| Illuminator On/Off Control |
Auto; Manual |
| Illuminator Number |
2 (Warm light) |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8 mm: H: 106°; V: 55°; D: 125°; 3.6 mm: H: 85°; V: 45°; D: 100° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 1.0 m (3.28 ft); 3.6 mm: 1.7 m (5.58 ft) |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
45.5 m (149.28 ft) |
18.2 m (59.71 ft) |
9.1 m (29.86 ft) |
4.6 m (15.09 ft) |
| 3.6 mm |
53.8 m (176.51 ft) |
21.5 m (70.54 ft) |
10.8 m (35.43 ft) |
5.4 m (17.72 ft) |
|
| Intelligence |
| IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| Smart Search |
Works with Smart NVR to perform intelligent search, event extraction and merging |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (sub stream only) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream: 1920 × 1080@(1–25/30 fps); Sub stream: 704 × 576@(1–25 fps) / 704 × 480@(1–30 fps) |
| Stream Capability |
2 streams |
| Resolution |
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps |
| Day/Night |
Color/B&W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (90°/270° supported at 1080p resolution and below) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G.726; PCM |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
| Interoperability |
ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host |
20 (Total bandwidth: 48 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 GB) |
| Browser |
IE; Chrome; Firefox |
| Management Software |
Smart PSS Lite; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Cybersecurity |
Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; X.509 certificate generation and import |
| Certification |
| Certifications |
CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Power |
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 2 W (12 VDC); 2.7 W (PoE); Max. (H.265+ with AI on + WDR + illuminator intensity): 6.2 W (12 VDC); 7.4 W (PoE) |
| Environment |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity |
≤95% |
| Ingress Protection |
IP67 |
| Construction |
| Casing Material |
Metal |
| Dimensions |
70.0 mm × 70.0 mm × 166.2 mm (2.76" × 2.76" × 6.54") (L × W × H) |
| Net Weight |
0.47 kg (1.04 lb) |
| Gross Weight |
0.59 kg (1.30 lb) |
