Stock Code: SD42215-HC-LA
| Camera | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Image Sensor | 1/2.8" STARVIS™ CMOS | ||||||||
| Pixel | 2MP | ||||||||
| Max. Resolution | 1920 (H) × 1080 (V) | ||||||||
| ROM | 16 MB | ||||||||
| RAM | 256 MB | ||||||||
| Electronic Shutter Speed | 1/3 s–1/100000 s | ||||||||
| Scanning System | Progressive | ||||||||
| Min. Illumination | Color: 0.005 Lux@F1.6 B/W: 0.0005 Lux@F1.6 | ||||||||
| Lens | |||||||||
| Focal Length | 5 mm–75 mm | ||||||||
| Max. Aperture | F1.6–F2.8 | ||||||||
| Field of View | H: 58.9–5.1; V: 34.1–2.9; D: 66.6–5.8 | ||||||||
| Optical Zoom | 15x | ||||||||
| Focus Control | Auto/Semi-Auto/Manual | ||||||||
| Close Focus Distance | 1 m–1.5 m (3.28 ft–4.92 ft) | ||||||||
| Iris Control | Auto/Manual | ||||||||
| DORI Distance |
| ||||||||
| PTZ | |||||||||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° | ||||||||
| Manual Control Speed | Pan: 300°/s; Tilt: 200°/s | ||||||||
| Preset Speed | Pan: 300°/s; Tilt: 200°/s | ||||||||
| Presets | 300 | ||||||||
| Tour | 8 (up to 32 presets per tour) | ||||||||
| Pattern | 5 | ||||||||
| Scan | 5 | ||||||||
| Speed Adjustment | Support | ||||||||
| Power-off Memory | Support | ||||||||
| Idle Motion | Preset/Tour/Pattern/Scanning | ||||||||
| Protocol | DH-SD Pelco-P/D (auto recognition) | ||||||||
| Video | |||||||||
| Resolution | 1080P (1920 × 1080); 720P (1280 × 720); D1 (704 × 576/704 × 480) | ||||||||
| Frame Rate | 1080P (25/30 fps); 720P (25/30/50/60 fps) | ||||||||
| Day/Night | Support | ||||||||
| BLC | Support | ||||||||
| WDR | 120 dB | ||||||||
| HLC | Support | ||||||||
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp | ||||||||
| Gain Control | Auto/Manual | ||||||||
| Noise Reduction | 2D/3D | ||||||||
| Motion Detection | Support | ||||||||
| Region of Interest (RoI) | Support | ||||||||
| Image Stabilization | Electronic | ||||||||
| Defog | Electronic | ||||||||
| Digital Zoom | 16x | ||||||||
| Flip | 0°/180° | ||||||||
| Privacy Masking | Up to 24 areas | ||||||||
| Audio | |||||||||
| Compression | G.711a; G.711Mu | ||||||||
| Function | |||||||||
| CVI Product Output Mode | CVI; TVI; AHD; CVBS | ||||||||
| Certification | |||||||||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL60950-1+CAN/CSA C22.2, No.60950-1 | ||||||||
| Port | |||||||||
| Analog Output | 1 (CVBS/CVI output, BNC port) | ||||||||
| RS485 | 1 (baud rate range: 1200 bps–9600 bps) | ||||||||
| Audio Input | 1 | ||||||||
| Alarm Input | 2 | ||||||||
| Alarm Output | 1 | ||||||||
| Power | |||||||||
| Power Supply | DC 12V/5A ± 10% | ||||||||
| Power Consumption | Basic: 9.6W Max: 12W (module zooming, PTZ operations) | ||||||||
| Environment | |||||||||
| Operating Temperature | -30°C ~ +60°C (-22°F ~ +140°F) | ||||||||
| Operating Humidity | ≤ 95%RH | ||||||||
| Protection | IP66; IK10; TVS 6000V lightning protection; surge protection | ||||||||
| Structure | |||||||||
| Dimensions | 155 mm × Φ170 mm (6.10" × Φ6.69") | ||||||||
| Net Weight | 1.8 kg (3.97 lb) | ||||||||
| Gross Weight | 3.3 kg (7.28 lb) | ||||||||
