Powers PoE devices and carries their traffic over a fiber uplink.
This is a managed Layer 2 industrial PoE switch for field cabinets. It distributes up to 96 W in total across four PoE ports, links to the fiber backbone through two SFP uplink ports and operates across -30°C ~ 65°C.
4PoE ports
96 WPoE Budget
6.8 GbpsSwitching Capacity
2 × 1000 Base-XSFP uplink ports
48 ~ 57 V DCPower Supply
-30°C ~ 65°COperating Temperature
Key features
96W
Total PoE Budget
Covers the power demand of the connected devices from a single supply.
60W
Hi-PoE Port
The fourth port alone feeds an end device with a high power draw.
6.8Gbps
Switching Capacity
Handles the traffic of all six ports in a single switching fabric.
8K
MAC Table
Learns device addresses on the network and ages out stale entries.
-30°C
Wide Temperature Range
Runs in unheated field cabinets.
4KV
Lightning Protection
Shields the line against common mode surges.
IN DAILY USEWeb and SNMP managementThe switch takes its settings from the web interface or over SNMP V1/V2C.
PoE controlTurns a port off and on remotely, so a frozen camera restarts without a site visit.
Ring topologySpanning Tree and loop detection keep redundant links free of loops.
The device starts up at the address 192.168.1.110/24 with an admin account that has no password.
