    4 x 8MP WizMind Multi-Sensor Panoramic Bullet IP Kamera
    Dahua

    4 x 8MP WizMind Multi-Sensor Panoramic Bullet IP Kamera

    Stock Code: IPC-PFW83242-A180

    Gathers a 180-degree scene into a 32 megapixel panorama with four sensors.
    This multi-sensor bullet camera merges four 1/1.8-inch sensors into a single panoramic image and outputs 8192 × 3840 pixels. Built-in IR illumination lights dark scenes up to 30 m, and the metal body is IP67 and IK10 rated.
    8192 × 3840Max. Resolution
    2.8 mmFocal Length
    180°Horizontal Field of View
    30 mIR Distance
    IP67Protection Grade
    24.3 WMax. Power Consumption
    Key features
    180°
    Panoramic single-body view
    Four sensors merge into one frame and cover a wide scene with a single camera.
    8192 × 3840pixels
    High-resolution panorama
    Distant detail stays readable across the wide scene.
    30m
    Illumination in the dark
    The built-in IR LED array lights the unlit scene in front of the camera.
    256GB
    Edge recording
    The Micro SD card keeps recording on the camera when the network drops.
    12V DC
    Power from one source
    The camera runs from a DC line and draws 13.6 W of basic power.
    84.0m
    Object detection range
    DORI figures place object detection at this distance.
    IN DAILY USE
    Wide coverage from one mountA single pole or facade point covers the area a multi-camera setup would need.
    Crowd and vehicle trackingThe crowd distribution map follows people density while vehicle density watches parking occupancy.
    Early warning at the lineTripwire and intrusion rules report movement across a defined line right away.
    Camera
    Image Sensor1/1.8" 8 Megapixel progressive CMOS
    Max. Resolution8192 (H) × 3840 (V)
    ROM4 GB
    RAM8 GB
    Scanning SystemProgressive
    Electronic Shutter SpeedAuto/Manual 1/3 s – 1/100,000 s
    Min. Illumination0.005 Lux@F1.6 (Color, 30IRE) / 0.0005 Lux@F1.6 (B/W, 30IRE) / 0 Lux (Illuminator on)
    S/N Ratio> 56 dB
    Illumination Distance30 m (98.4 ft) (IR LED)
    Illuminator On/Off ControlAuto/Manual
    Illuminator Number8 (IR LED)
    Pan/Tilt/Rotation RangeTilt: 0° – 90° / Rotation: 0° – 360°
    Lens
    Lens TypeFixed-focal
    Mount TypeM12
    Focal Length2.8 mm
    Max. ApertureF1.6
    Field of ViewHorizontal: 180°; vertical: 90°
    Iris TypeFixed
    Close Focus Distance1.8 m (5.9 ft)
    DORI Distance
    DetectObserveRecognizeIdentify
    84.0 m (275.6 ft)33.6 m (110.2 ft)16.8 m (55.1 ft)8.4 m (27.6 ft)
    Professional, intelligent
    Vehicle DensityVehicle density; parking upper limit; vehicle congestion alarm
    IVS (Perimeter Protection)Intrusion; tripwire
    Crowd Distribution MapCrowd map, global people counting; people counting in area
    Video
    Video CompressionH.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
    Smart CodecSmart H.264+/Smart H.265+
    Video Frame RateMain stream: 8192 × 3840 (1 – 25/30 fps) / Sub stream: 1280 × 600 (1 – 25/30 fps) / Third stream: 2304 × 1080 (1 – 25/30 fps)
    Stream Capability3 streams
    ResolutionSplicing: 32M (8192 × 3840); 7680 × 3600; 7168 × 3360; 6720 × 3152; 5760 × 2700; 4800 × 2252; 4096 × 1920; 2880 × 1360; 2304 × 1080; 1280 × 600; 2408 × 960; 1520 × 712 / Non-splicing: 4320 × 7680; 2880 × 5120; 2160 × 3840; 720 × 1280; 1080 × 1920
    Bit Rate ControlCBR/VBR
    Video Bit RateH.264: 96 kbps – 65536 kbps / H.265: 38 kbps – 55612 kbps
    Day/NightAuto (ICR)/Color/B/W
    BLCYes
    HLCYes
    WDRDWDR
    White BalanceAuto/natural/street lamp/outdoor/manual/regional custom
    Gain ControlAuto/Manual
    Noise Reduction3D NR
    Motion DetectionOFF/ON (4 areas, rectangular)
    Region of Interest (RoI)Yes (4 areas)
    Smart IlluminationYes
    Privacy Masking4 areas
    Audio
    Audio CompressionG.711A; G.711Mu; G.726; G.723
    Alarm Event
    Alarm EventNo SD card; SD card full; SD card error; service life warning; network disconnection; IP conflict; illegal access; voltage detection; safety exception; motion detection; video tampering; scene changing; input abnormal detection; intensity change detection; external alarm; tripwire; intrusion; crowd density detection; traffic congestion; maximum vehicle
    Network
    NetworkRJ-45 (10/100/1000 Base-T)
    SDK and APIYes
    Cyber SecurityVideo encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
    ProtocolIPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour
    InteroperabilityONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; RTMP
    User/Host20
    StorageFTP; SFTP; Micro SD card (support max. 256 GB); NAS
    BrowserIE10 and later
    Management SoftwareSmart PSS; DSS
    Certification
    CertificationsCE-LVD: EN62368-1 / CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU / FCC: 47 CFR FCC Part 15, Subpart B / UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
    Port
    RS-4851 (baud rate range: 1200 bps – 115200 bps)
    Audio Input1 channel (RCA port)
    Audio Output1 channel (RCA port)
    Alarm Input2 channels in: 5 mA 3 V – 5 V DC
    Alarm Output2 channels out: 1000 mA 30 V DC/500 mA 50 V DC
    Power
    Power Supply12 V DC
    Power ConsumptionBasic power consumption: 13.6 W (12 V DC) / Max. power consumption (Intelligent functions enabled + IR full intensity + WDR): 24.3 W (12 V DC)
    Environment
    Operating Temperature-40°C to +60°C (-40°F to +140°F)
    Operating Humidity≤ 95%
    Storage Temperature-40°C to +60°C (-40°F to +140°F)
    Ingress ProtectionIP67; IK10
    Structure
    CasingMetal
    Dimensions298.3 mm × 172.5 mm × 120.5 mm
    Net Weight3.16 kg (7.0 lb)
    Gross Weight4.06 kg (9.0 lb)
