| Camera |
| Image Sensor |
1/2.9" CMOS |
| Max. Resolution |
2688 (H) × 1520 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto / Manual, 1/3 s–1/100,000 s |
| Min. Illumination |
0.005 lux@F1.5 (Color, 30 IRE); 0.0005 lux@F1.5 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio |
> 56 dB |
| IR Distance |
Up to 60 m (196.85 ft) |
| Illuminator On/Off Control |
Auto / Manual |
| Illuminator Number |
4 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Motorized vari-focal |
| Lens Mount |
φ14 |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.5 |
| Field of View |
Horizontal: 104°–29°; Vertical: 54°–16°; Diagonal: 125°–33° |
| Iris Control |
Fixed |
| Close Focus Distance |
0.8 m (2.62 ft) |
| DORI Distance |
| Lens | Detect | Observe | Recognize | Identify |
|---|
| W | 64.0 m (209.97 ft) | 25.6 m (83.99 ft) | 12.8 m (41.99 ft) | 6.4 m (21.00 ft) | | T | 210.0 m (688.98 ft) | 84.0 m (275.60 ft) | 42.0 m (137.80 ft) | 21.0 m (68.90 ft) |
|
| DORI Note |
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN 62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
| Intelligence |
| IVS (Perimeter Protection) |
Tripwire, intrusion (support the classification and accurate detection of vehicle and human) |
| AI SSA |
Yes |
| Quick Pick |
With AI NVR, quickly pick up the human/vehicle targets of interest from SMD events |
| Smart Search |
Work together with Smart NVR to perform refined intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2688 × 1520 @ (1–25/30) fps; Sub stream 1: 704 × 576 @ (1–25 fps) / 704 × 480 @ (1–30 fps); Sub stream 2: 1920 × 1080 @ (1–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); CIF (352 × 288 / 352 × 240); VGA (640 × 480) |
| Bit Rate Control |
CBR / VBR |
| Video Bit Rate |
H.264: 3 kbps–8192 kbps; H.265: 3 kbps–8192 kbps |
| Day/Night |
Auto (ICR) / Color / B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF / ON (4 areas, rectangular) |
| Image Stabilization |
Electronic Image Stabilization (EIS) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Defog |
Yes |
| AFSA |
Yes |
| Image Rotation |
0°/90°/180°/270° (support 90°/270° with 2688 × 1520 resolution and below) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; lifetime warning (only Dahua card supports); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; SMD; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certificate; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI |
| User/Host |
20 (Total bandwidth: 64 M) |
| Storage |
FTP; SFTP; Micro SD card (max. 256 GB); NAS |
| Browser |
IE: IE11; Chrome; Firefox |
| Management Software |
SmartPSS Lite; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Certification |
| Certifications |
CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL 62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Audio Input |
1 channel (RCA port) (Only -ZAS supports) |
| Audio Output |
1 channel (RCA port) (Only -ZAS supports) |
| Alarm Input |
1 channel in: wet contact, 5 mA, 3 V–5 VDC (Only -ZAS supports) |
| Alarm Output |
1 channel out: wet contact, 300 mA, 12 VDC (Only -ZAS supports) |
| Power |
| Power Supply |
12 VDC / PoE (802.3af) |
| Power Consumption |
Basic: 2.8 W (12 VDC); 3.6 W (PoE). Max. (WDR + IR intensity + Intelligence): 7.9 W (12 VDC); 9.2 W (PoE) |
| Environment |
| Operating Temperature |
–30 °C to +60 °C (–22 °F to 140 °F) / Less than 95% RH |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to 140 °F) |
| Protection |
IP67 |
| Structure |
| Casing |
Metal |
| Product Dimensions |
244.1 mm × 79.0 mm × 75.9 mm (9.61" × 3.11" × 3.00") |
| Net Weight |
820 g (1.81 lb) |
| Gross Weight |
1090 g (2.40 lb) |
