| Camera |
|---|
| Image Sensor | 1/1.8" 4 Megapixel progressive CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 4 GB |
| RAM | 2 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| Min. Illumination | 0.001 Lux@F1.2 (Color, 30IRE) / 0.0002 Lux@F1.2 (B/W, 30IRE) / 0 Lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Illumination Distance | 60 m (196.85 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 4 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360° |
| Lens |
|---|
| Lens Type | Motorized vari-focal |
| Mount Type | Module interface |
| Focal Length | 2.7 mm–12 mm |
| Max. Aperture | F1.2 |
| Field of View | Horizontal: 114°(W)–47°(T) / Vertical: 59°(W)–27°(T) / Diagonal: 141°(W)–55°(T) |
| Iris Type | Auto; precise iris control |
| Close Focus Distance | W: 1 m (3.28 ft) / T: 2.5 m (8.20 ft) |
| DORI Distance | | Lens | Detect | Observe | Recognize | Identify |
|---|
| W | 60.1 m (197.18 ft) | 24 m (78.74 ft) | 12 m (39.37 ft) | 6 m (19.69 ft) | | T | 128.6 m (421.92 ft) | 51.4 m (168.64 ft) | 25.7 m (84.32 ft) | 12.8 m (41.99 ft) |
|
| Smart Event |
|---|
| IVS | Abandoned object, moving object |
| Professional, Intelligent |
|---|
| IVS (Perimeter Protection) | Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering |
| Face Detection | Face detection, track, priority, snapshot, upload optimized snapshot picture; face enhancement, face exposure, face attribute extract (6 attributes and 8 expressions: gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mouth mask, beard); face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, priority snapshot, quality priority; face angle filter, priority time setting; support non-living filtering |
| Face Recognition | Two modes: General and Counting. General: face detection, track, snapshot, enhancement, attribute extract (6 attributes, 8 expressions), 5 face databases (50,000 face images in total), non-living filtering. Counting: advanced customer counter, specific face database filtering, reporting |
| Face & Body Detection | Two modes: General and PPE Detection. General: face and human detection can be enabled simultaneously and trigger alarms. PPE Detection: detects mask, helmet, glasses, vest, upper and lower clothing color, determines PPE compliance and triggers alarms |
| ANPR | ANPR, track, priority, snapshot; vehicle attributes: license plate, vehicle type, vehicle color, vehicle brand; other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark |
| Video Metadata | Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction |
| People Counting | Support tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports; support queue management, and displaying and outputting monthly/daily reports; support 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions |
| Intelligent Search | Work together with Smart NVR to perform refined intelligent search, event extraction and merging to event videos |
| Video |
|---|
| Video Compression | H.265, H.264, H.264H, H.264B, MJPEG (only supported by sub stream) |
| Smart Codec | Smart H.265+/Smart H.264+ |
| Video Frame Rate | Main Stream: 2688 × 1520 (1–50/60 fps) / Sub Stream: 704 × 576 (1–25 fps); 704 × 480 (1–30 fps) / Third Stream: 1920 × 1080 (1–25/30 fps) / Fourth Stream: 1920 × 1080 (1–25/30 fps) / Fifth Stream: 704 × 576 (1–25 fps); 704 × 480 (1–30 fps) |
| Stream Capability | 5 streams |
| Resolution | 4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–10240 kbps / H.265: 12 kbps–10240 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Electronic Image Stabilization (EIS) | Yes |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution or below) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
|---|
| Audio Compression | G.711a; G.711Mu; G726; G.723 |
| Alarm |
|---|
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception; queue management |
| Network |
|---|
| Network | RJ-45 (10/100/1000 Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P; RTMP |
| User/Host | 20 (Total bandwidth: 80M) |
| Storage | FTP; Micro SD card (256 G); NAS; SFTP |
| Browser | IE: IE9 and later / Chrome: Chrome 42 and later / Firefox: Firefox 48.0.2 and later |
| Management Software | Smart PSS; DSS; DMSS |
| Mobile Phone | IOS, Android |
| Certification |
|---|
| Certifications | CE-LVD: EN62368-1, EN60950-22 (optional); CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07, UL 50E NEMA Type 4X (optional) |
| Port |
|---|
| RS-485 | 1 (Bit rate: 1200 bps–115200 bps) |
| Audio Input | Audio Interface: 1/1 channel In/Out |
| Audio Output | Audio Interface: 1/1 channel In/Out |
| Alarm Input | 3 channel In: 5 mA 5 V DC / 2 channel Out: 1000 mA 30 V DC / 500 mA 50 V AC |
| Alarm Output | 3 channel In: 5 mA 5 V DC / 2 channel Out: 1000 mA 30 V DC / 500 mA 50 V AC |
| Power |
|---|
| Power Supply | 12V DC/24V AC/PoE+ (802.3at); ePoE |
| Power Consumption | Basic power consumption: 3.7W (12V DC); 5.7W (24V AC); 5.5W (PoE) / Max. power consumption (Max. stream + intelligent function + IR LED + focus): 12.2W (12V DC); 17.3W (24V AC); 17.1W (PoE) / Heat power consumption: 3.3W (12V DC); 5.5W (24V AC); 5.5W (PoE) |
| Environment |
|---|
| Operating Conditions | –40°C to +60°C (–40°F to +140°F) / Less than 95% RH |
| Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
| Protection Grade | IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional) |
| Structure |
|---|
| Casing | Metal + Plastic |
| Dimensions | 340.1 mm × 108.5 mm × 92.9 mm (13.39" × 4.27" × 3.66") (L × W × H) |
| Net Weight | 1600 g (3.53 lb) |
| Gross Weight | 2400 g (5.29 lb) |
